Detailed description
Item:SA15C SI15C 15*40*12mm
Type: Rod end Bearings
Lubrication: Oil or Grease
Dimensions:15mmx40mmx12mm/Metric
ID (inner diameter)/Bore: 15mm
OD (outer diameter): 40mm
Width/Height/thickness: 12mm
Male Radial Static Load:40KN
Female Radial Load:49KN
Carbon Steel Standard Duty Alloy Steel Duty Available.
Notes:
1.For alloy steel duty add ”/H” to suffix, example: SA15C/H. For load rating of alloy steel duty, please consult Unifor Technology Department.
2.Add ”L” to prefix to indicate left hand thread, example: SIL15C/H.
3.Fine thread M10x1.25 M12x1.25 M16x1.5 are available.
4.Die forged bodies are available for size d≥12mm.
| Rod End No | Dimensions in Millimeters | Radial Static Load(KN) | |||||||
| d | B | d2max | d3 | Male | Female | ||||
| Male | Female | h | d5max | Male | Female | ||||
| SA15C | SI15C | 15 | 12 | 40 | M14 | 63 | 26 | 40 | 49 |
