RMS5-2RS ZZ Deep Groove Ball Bearings For Machine
Reference FOB Price:
US2 ~ 4 / Piece
Min. Order:
2 Piece
Payment term:
D/T LC T/T
Delivery time:
5-7days
Technical Parameters:
Product Designations:
RMS5-2RS ZZ
Structure:
Ball
Inside Diameter:
15.875 mm
Outside Diameter:
46.04 mm
Thickness:
15.88 mm
Brand:
YEK
Precision Rating:
P5
Cage material:
Steel Retaier
Seal Material:
Rubber Seals
Shipping Ways:
By sea or by air
RMS5 ZZ 2RS Deep Groove Ball Bearings
0.625*1.812*0.625inch Bearing Features:
Inner Ring Diameter (bore): 5/8
Outer Ring Diameter: 1 13/16
Width: 5/8
| Bearing NO. |
Boundary dimensions(mm) | ||
| d | D | B | |
| RMS4 | 12.7 | 41.28 | 15.88 |
| RMS5 | 15.875 | 46.04 | 15.88 |
| RMS6 | 19.05 | 50.8 | 17.46 |
| RMS7 | 22.225 | 57.15 | 17.46 |
| RMS8 | 25.4 | 63.5 | 19.05 |
| RMS9 | 28.575 | 71.44 | 20.64 |
| RMS10 | 31.75 | 79.37 | 22.23 |
| RMS11 | 34. 925 | 88.9 | 22.23 |
| RMS12 | 38.1 | 95.25 | 22.81 |
| RMS13 | 41.275 | 101.0 | 23.81 |
| RMS14 | 44.45 | 108 | 26.99 |
| RMS15 | 47.625 | 114.3 | 26.99 |
| RMS16 | 50.8 | 114.3 | 26.99 |
| RMS18 | 57.15 | 127 | 31.75 |
| RMS20 | 63.5 | 139.5 | 31.75 |
| RMS22 | 69.85 | 158.8 | 34.93 |
