QJ212-XL-MPA Bore 60 Mm, Four Point Contact Bearings, Solid Brass Cage

🔍

QJ212-XL-MPA

Bore Diameter:60 mm

Outside Diameter:110 mm

Width:22 mm

Weight:0.945 kg

Min. Order:1 Piece

The QJ212-XL-MPA Four-point contact ball bearings are widely used in equipment requiring space and complex load-bearing capacity, such as industrial robots (wrist joints), machine tools (rotary tables), medical equipment (CT scanner rotating frames), radar antennas, solar tracking systems, and lifting machinery.

The QJ212-XL-MPA bearing is a Four point contact bearings with an inner diameter of 60 mm , an outer diameter of 110 mm, a width of 22 mm. It typically uses PN (ABEC-1) grade precision tolerances and GCr15SiMn rings, GCr15SiMn rolling mlement. Its dynamic radial rated load is approximately 93885 N, its static radial rated load is approximately 86909 N. It uses CN standard radial clearance, Open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Interchange code: QJ212-MPA

Dimensions:

Inside Diameter:

60 mm

Outside Diameter:

110 mm

Thickness:

22 mm

Weight:

0.945 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

93885 N

Static load Capacity, Radial (Cor):

86909 N

Fatigue Load Limit, Radial:

6070 N

Reference speed (Grease rpm):

5368

Limiting speed (Oil rpm):

12257

Specifications:

Old Designations:

QJ212-MPA

Structure:

Four-point contact ball bearings

Number of Rows:

One

Radial Clearance Trade No.:

Precision Rating:

PN (ABEC-1)

Bearing Material:

GCr15SiMn

Cage Type:

MPA = solid brass cage, outer ring guided

Seals Type:

Open

Rolling Mlement Material:

GCr15SiMn

Bore Type:

Cylindrical bore

Operating Temperature:

-30 to 150 °C

System of Measurement:

Metric

Series:

QJ2 series (QJ2..-XL-MPA)

Rolling Element:

balls

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

QJ212-XL-MPA bearings ( 60 mm x 110 mm x 22 mm) have the advantages of Bidirectional load-bearing capacity, space-saving, and high rigidity, and are therefore widely used in the Gearboxes, compressors, lifting machinery.

Part Number	QJ212-XL-MPA
Bearing Type	Four point contact bearings
Cage	MPA = solid brass cage, outer ring guided
Internal clearance	CN
Type	QJ
Heat stabilization	S0 = up to 150°C
Manufacturer Part Code	QJ212-MPA
Equivalent	QJ212-MPA
Contact angle - α	35 °
X-Life	XL
Bearing Mass - m [lb]	2.0833
Performance
Radial Dynamic - C_r [lbf]	21105
Radial static - C_0r [lbf]	19537
Radial Fatigue - C_ur [lbf]	1364
Reference speed - n_ϑr [min^–1]	5368
Limiting speed - n_G [min^–1]	12257
Dimension
Inside - d φ [inch]	2.3622
Outside - D Φ [inch]	4.3307
Width - B [inch]	0.8661
r(min.) [inch]	0.0591
D₁ [inch]	3.6594
d₁ [inch]	3.0335
a [inch]	2.3425
Mounting dimensions
d_a(min.) [inch]	2.7165
D_a(max.) [inch]	3.9764
r_a(max.) [inch]	0.0591

The QJ212-XL-MPA Four-point contact ball bearings primarily consist of an inner ring (usually a double-half inner ring or an integral one), an outer ring, steel balls, and a cage. The raceways are Gothic arched, and the steel balls form four-point contact with the inner and outer rings. Gears can be integrated into the inner and outer rings, resulting in a compact structure.

A single set of four-point contact ball bearings can simultaneously withstand radial loads, bidirectional axial loads, and overturning moments, eliminating the need for paired installation. They feature low axial height and light weight, saving installation space. They possess high rigidity and low friction characteristics, making them suitable for light to medium load conditions.
