POS5 Rod End (Size:5x16x41mm)

🔍

POS5

Bore Diameter:5 mm

Outside Diameter:16 mm

Width:41 mm

Weight:0.016 kg

Min. Order:1 Piece

The POS5 bearing is a Rod Ends with an inner diameter of 5 mm , an outer diameter of 16 mm, a width of 41 mm. Its dynamic radial rated load is approximately 3.3, its static radial rated load is approximately 3.9. together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Application: Hydraulic cylinders, Vehicle suspensions, Articulated joints, Heavy duty linkage pivots, High load hitch assemblies

Dimensions:

Inside Diameter:

5 mm

Outside Diameter:

16 mm

Thickness:

41 mm

Weight:

0.016 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

3.3

Static load Capacity, Radial (Cor):

3.9

Specifications:

Structure:

Rod Ends

Demensions:

5x16x41

Brand:

Neutral Product

Bearing Material:

Carbon Steel & Zinc Plated Rod End Body, Chrome Steel Inner Ring, Sliding Surfac

Series:

POS

Surface Coating:

Zinc Coated

Transaction Information:

Transport Package:

Standard Export Package

Shipping Ways:

by Sea or Air

Country of Origin:

China

Stock:

100 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

POS5 Male Threaded Rod End

Size: 5x16x41mm

Bore Diameter Bearing (d): 5mm

Outer Eye Diameter (d2): 16mm

Total Length Internal Thread Head (L2): 41mm

POS5 male thread rod end has a sliding contact surface: steel/bronze. Rod end of steel and zinc coated, sliding surface with bronze liner, inner ring of carbon chromium steel, spherical surface with chromium plating; can be lubricated via a nipple or a hole in the rod end. With large loading capability, easy mounting and dismounting.

For left-hand thread, please add suffix “L”, E.G. POSL5.

Applications:
1. Agricultural Machinery
2. Gardening Machinery
3. Pneumatics and Hydraulics
4. Fitness Machines
5. Lifting Equipment
6. Heavy Trucks
7. Food Machinery

POS5 Male Threaded Rod End

Bearing Number

Boundary dimensions (mm)

B
0
-0.12

C1
max

d2 max

G
6g

L1 min

L2 max

r1s
min

a°
≈

Radial Clearance mm

Weight (kg)

POS5

5
+0.012

11.112

M5x0.8

0.3

0-0.035

0.016

All the bearings we are offering are direct factory price, fast delivery, perfect quality. For more bearings, please feel free to mail us at [email protected], or contact us by Wechat or Whatsapp at +8618062246726.
