Plastic Molded Cage BSF50140DDUHP2BDT Angular Contact Super Precision Bearings For Ball Screw Support
The BSF50140DDUHP2BDT Ball screw support bearings are widely used in the feed drive systems of CNC machine tools, specifically including: machining centers (X/Y/Z axis screw support), CNC lathes (Z-axis), EDM machines, precision grinding machines, industrial robots (linear modules), and semiconductor equipment (wafer positioning platforms).
The BSF50140DDUHP2BDT bearing is a Double-Row Angular Contact Super Precision Thrust Ball Bearings, BSF Type Matched DT pairs for Ball Screw Support with an inner diameter of 50 mm , an outer diameter of 140 mm, a width of 108 mm. It typically uses P2B = ISO Class 2 grade precision tolerances and GCr15SiMn rings, GCr15SiMn rolling mlement. Its dynamic axial rated load is approximately 187621 N, its static axial rated load is approximately 439741 N. DDU = Rubber contact seal on both sides type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.
BSF50140DDUHP2BDT bearings ( 50 mm x 140 mm x 108 mm) have the advantages of High axial stiffness and load-bearing capacity, 60° contact angle design, pre-installed and pre-loaded for easy installation, optional sealing for maintenance-free operation, and are therefore widely used in the Machine tool ball screws, machining centers, automated equipment, robots, precision measuring devices.
| Part Number | BSF50140DDUHP2BDT |
| Bearing Type | Double-Row Angular Contact Super Precision Thrust Ball Bearings, BSF Type Matched DT pairs for Ball Screw Support |
| Internal design | F = Flange type |
| Type | BS = BSBD Series |
| Preload | H = Heavy preload |
| Arrangement row | Two |
| Arrangement | DT = Double row Tandem |
| Bearing Mass - m [lb] | 19.6650 |
| Pitch Diameter of Holes for Bolts - J [inch] | 4.4488 |
| Extraction groove position - I [inch] | 3.8976 |
| Extraction groove position - b [inch] | 0.1181 |
| Number of bolts x Pitch - t (mm) | 12 x 30 ° |
| Bolt type | Ⅱ |
| Bolt Dia. | M10 |
| Number of Bolts | 12 |
| Starting Torque - H | 2.11 N･m |
| Recommended Clamping Force - T [lbf] | 4229 |
| Dynamic Axial - Ca [lbf] | 42177 |
| Static Axial - C0a [lbf] | 98853 |
| Limiting static axial load [lbf] | 67186 |
| Speed ratings (grease) - nB | 2483 min–1 |
| Axial Rigidity | 2671 N/µm |
| Dimension | |
| d φ Inside [inch] | 1.9685 |
| D Φ Outside [inch] | 5.5118 |
| 2B Total Width [inch] | 4.2520 |
| r min Chamfer [inch] | 0.0236 |
| r1 min Chamfer [inch] | 0.0236 |
| d1 Shoulder [inch] | 3.0748 |
| d2 Shoulder [inch] | 0.4331 |
| D1 Shoulder/Recess [inch] | 3.8386 |
The BSF50140DDUHP2BDT Ball screw support bearings are typically composed of high-precision angular contact ball bearings paired back-to-back (DB) or in series (DT) configurations. They feature a small contact angle (15° or 20°) and high-rigidity cages (phenolic resin or brass) on both inner and outer rings, achieving a precision grade of P4 or higher. Some models integrate seals and lubrication holes, forming a preload unit.
Ball screw support bearings offer extremely high axial rigidity and load-bearing capacity, accurately withstanding bidirectional axial loads in screw drives. The back-to-back configuration provides anti-overturning moment capability, ensuring positioning accuracy. The preload design eliminates axial backlash, achieving backlash-free, low-friction operation with low heat generation, making them suitable for high-speed feed. They are factory-installed and ready to use, simplifying installation and adjustment.
