PHS30 Rod End (Size:30x70x145mm)

PHS30 Rod End (Size:30x70x145mm)

Min. Order:
1 Piece
Stock:
100 Piece
Port:
Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao
Payment term:
by T/T in advance
Delivery time:
2-3 days for stock, 25-30 days for bulk production
Skype online
QQ online
Mobile NO.: +86-18062246726
Technical Parameters:
Product Designations:
PHS30
Structure:
Rod Ends
Inside Diameter:
30 mm
Outside Diameter:
70 mm
Thickness:
145 mm
Weight:
1.13 KG
Dynamic load Capacity, Radial (Cr):
63
Static load Capacity, Radial (Cor):
86
Demensions:
30x70x145
Brand:
Neutral Product
Bearing Material:
Carbon Steel & Zinc Plated Rod End Body with Chrome Steel Bearing
Transport Package:
Standard Export Package
Shipping Ways:
by Sea or Air
Country of Origin:
China
Series:
PHS
Application:
Hydraulic cylinders, Vehicle suspensions, Articulated joints, Heavy duty linkage pivots, High load hitch assemblies
PHS30 Rod End (Size:30x70x145mm)
PHS30 Heavy Duty Rod End Bearing

Size: 30x70x145mm

Bore Diameter Bearing (d): 30mm
Outer Eye Diameter (d2): 70mm
Total Length Internal Thread Head (L4): 145mm

PHS30 Heavy-duty female thread rod ends, sliding surface with bronze liner; inner ring of carbon chromium steel, spherical surface with chromium plating; can be lubricated via a nipple or a hole in the rod end. With large loading capability, easy mounting and dismounting.

For left-hand thread, please add suffix “L”, E.G. PHSL30.

Applications:
1. Agricultural Machinery
2. Gardening Machinery
3. Pneumatics and Hydraulics
4. Fitness Machines
5. Lifting Equipment
6. Heavy Trucks
7. Food Machinery

PHS30 Heavy Duty Rod End Bearing
Bearing Number Boundary dimensions (mm)
d
H7
B
0
-0.12
dk C1
max
d2 max G
6H
h1 L3 min L4 max L5 W d4 d5 rs
min

Radial clearance mm Weight (kg)
PHS30 30
+0.021
37 50.8 25 70 M30x2 110 51 145 15 41 40 50 0.6 17 0-0.035 1.13

All the bearings we are offering are direct factory price, fast delivery, perfect quality. For more bearings, please feel free to mail us at sales@partsservicesupply.com, or contact us by Wechat or Whatsapp at +8618062246726.
