PHS18 Rod End (Size:18x42x92mm)

🔍

PHS18

Bore Diameter:18 mm

Outside Diameter:42 mm

Width:92 mm

Weight:0.295 kg

Min. Order:1 Piece

The PHS18 bearing is a Rod Ends with an inner diameter of 18 mm , an outer diameter of 42 mm, a width of 92 mm. Its dynamic radial rated load is approximately 26, its static radial rated load is approximately 30. together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Application: Hydraulic cylinders, Vehicle suspensions, Articulated joints, Heavy duty linkage pivots, High load hitch assemblies

Dimensions:

Inside Diameter:

18 mm

Outside Diameter:

42 mm

Thickness:

92 mm

Weight:

0.295 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

Static load Capacity, Radial (Cor):

Specifications:

Structure:

Rod Ends

Demensions:

18x42x92

Brand:

Neutral Product

Bearing Material:

Carbon Steel & Zinc Plated Rod End Body with Chrome Steel Bearing

Series:

PHS

Transaction Information:

Transport Package:

Standard Export Package

Shipping Ways:

by Sea or Air

Country of Origin:

China

Stock:

100 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

PHS18 Heavy Duty Rod End Bearing

Size: 18x42x92mm

Bore Diameter Bearing (d): 18mm

Outer Eye Diameter (d2): 42mm

Total Length Internal Thread Head (L4): 92mm

PHS18 Heavy-duty female thread rod ends, sliding surface with bronze liner; inner ring of carbon chromium steel, spherical surface with chromium plating; can be lubricated via a nipple or a hole in the rod end. With large loading capability, easy mounting and dismounting.

For left-hand thread, please add suffix “L”, E.G. PHSL18.

Applications:
1. Agricultural Machinery
2. Gardening Machinery
3. Pneumatics and Hydraulics
4. Fitness Machines
5. Lifting Equipment
6. Heavy Trucks
7. Food Machinery

PHS18 Heavy Duty Rod End Bearing

Bearing Number

Boundary dimensions (mm)

d
H7

B
0
-0.12

C1
max

d2 max

G
6H

L3 min

L4 max

rs
min

a°
≈

Radial clearance mm

Weight (kg)

PHS18

18
+0.018

31.75

16.5

M18x1.5

0.6

0-0.035

0.295

All the bearings we are offering are direct factory price, fast delivery, perfect quality. For more bearings, please feel free to mail us at [email protected], or contact us by Wechat or Whatsapp at +8618062246726.
