NN3010KCC9P4YU17 Double Row Cylindrical Roller Bearing 50x80x23 Mm

🔍

NN3010KCC9P4YU17

Bore Diameter:50 mm

Outside Diameter:80 mm

Width:23 mm

Weight:0.436 kg

Min. Order:1 Piece

The NN3010KCC9P4YU17 bearing is a Cylindrical roller beairngs with an inner diameter of 50 mm , an outer diameter of 80 mm, a width of 23 mm. It typically uses P4 grade precision tolerances and features a Steel cage, GCr15 Chrome Steel rings. It primarily bears Axial/Radial, Its dynamic radial rated load is approximately 53 kN, its static radial rated load is approximately 72.5 kN. It uses CC9 standard radial clearance, Open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Feature: 3 Rib Inner Ring | Plain Outer Ring

Application: Manufacturing Plant, Energy & Mining

Dimensions:

Inside Diameter:

50 mm

Outside Diameter:

80 mm

Thickness:

23 mm

Weight:

0.436 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

53 kN

Static load Capacity, Radial (Cor):

72.5 kN

Reference speed (Grease rpm):

7500 1/min

Limiting speed (Oil rpm):

9000 1/min

Specifications:

Old Designations:

NN3010K

HS Code:

8482500090

Structure:

Cylindrical Roller Bearings

Number of Rows:

Demensions:

50x80x23 mm

Brand:

As Per Requirements

Radial Clearance Trade No.:

CC9

Precision Rating:

Vibration:

ZV1, ZV2, ZV3

Load Direction:

Axial/Radial

Bearing Material:

Bearing Steel

Cage Type:

S - Steel or Standard Cage

Cage material:

Steel

Seals Type:

Open

Roller Material:

GCr15 Chrome Steel

Bore Type:

K - 1:12 Tapered Bore (Standard for Most Types)

Operating Temperature Range:

Up to 120 °C

Series:

NN3000

Rolling Element:

Cylindrical roller bearing

Suffix Description:

K: Tapered Bore, Taper 1: 12

Snap Ring:

Transaction Information:

Transport Package:

Box+Pallet

Service:

OEM Service

Shipping Ways:

DHL / TNT / UPS / ARMEX / FEDEX ,Etc

Country of Origin:

Japan

Quality Control:

ISO9001:2015

Stock:

450 Piece

Production Capacity:

10000pcs/year

Port:

Shanghai/Qingdao/Guangzhou/Hongkong

Payment term:

TT/Western Union/Paypal

Delivery time:

3~5 days

Detailed description

NN3010KCC9P4YU17 Double Row Cylindrical Roller Bearing 50x80x23 mm

Cylindrical Roller Bearing, NN3010KCC9P4YU17, 50x80x23 mm, Steel Cage, P4 Precision Grade, Double Row, Outer Ring - two Sides Separable; No Snap Ring, Relubricatable, CC9.

K: Tapered Bore, Taper 1: 12

Part Number	NN3010KCC9P4YU17	Package	Carton Box+Pallet
Size:	50x80x23 mm	Material	Bearing steel
Bore diameter (d):	50 mm (1.969 Inch)	Place of Origin	Japan
Outside Diameter (D):	80 mm (3.15 Inch)	Structure	Cylindrical Roller Bearing
Width, outer ring (T):	23 mm (0.906 Inch)	Sealing	No seal
Profile	Complete with Outer and Inner Ring	Grease Limiting Speed (r/min)	7500 1/min
Relubricatable	Yes	Oil Limiting Speed (r/min)	9000 1/min
Radial internal clearance	CC9	EW	72.5 mm
Precision Grade	P4	CR2	5400 kgf
Number of Row	2	COR2	7400 kgf
MOQ	1PCS	Certifications	ISO9001:2015
Weight	0.436 KG	Basic dynamic load rating	53 kN
Payment Term	TT or Western Union	Basic static load rating	72.5 kN
Brand Name	As per requirement	Lead Time	3~5 Days
Bore type	K - 1:12 Tapered Bore (Standard for Most Types)	Application	Manufacturing Plant, Energy & Mining
Bore Profile	Tapered	Snap Ring	No
Heat Stabilization	Temperatures up to 120 °C	Seperable	Outer Ring - Two Sides
DA1	55 mm	D1A	56 mm
DA3	75 mm	DA4	74 mm
RA	1.0 mm	R	1.0 mm
r min	1.0 mm	Retainer	Yes
Cage Type	S - Steel or Standard Cage	Other Features	3 Rib Inner Ring \| Plain Outer Ring
