NJ207E.M1.C3 Single Row Cylindrical Roller Bearing 35x72x17 Mm

🔍

NJ207E.M1.C3

Bore Diameter:35 mm

Outside Diameter:72 mm

Width:17 mm

Weight:0.295 kg

Min. Order:1 Piece

The NJ207E.M1.C3 bearing is a Cylindrical roller beairngs with an inner diameter of 35 mm , an outer diameter of 72 mm, a width of 17 mm. It typically uses P6 P5 P4 grade precision tolerances and features a Brass cage, Bearing Steel rings. It primarily bears Axial/Radial, Its dynamic radial rated load is approximately 59 kN, its static radial rated load is approximately 50 kN. It uses C3 standard radial clearance, Open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Feature: 2 Rib Inner Ring, Plain Outer Ring, Cage on Inner Ring OD, High Capacity, Medium Series, X Life Bearing

Application: gearboxes, agricultural machinery, pumps, compressors, and electric motors

Dimensions:

Inside Diameter:

35 mm

Outside Diameter:

72 mm

Thickness:

17 mm

Weight:

0.295 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

59 kN

Static load Capacity, Radial (Cor):

50 kN

Fatigue Load Limit, Radial:

7.7 kN

Reference speed (Grease rpm):

14100 r/min

Limiting speed (Oil rpm):

8100 r/min

Specifications:

Old Designations:

NJ207EM1

HS Code:

8482500090

Structure:

Cylindrical Roller Bearing

Number of Rows:

Demensions:

35x72x17 mm

Brand:

As Per Requirements

Radial Clearance Trade No.:

Precision Rating:

P6 P5 P4

Vibration:

ZV1/ZV2/ZV3

Load Direction:

Axial/Radial

Bearing Material:

Bearing Steel

Cage Type:

Brass Cage

Cage material:

Brass

Seals Type:

Open

Roller Material:

Bearing Steel

Bore Type:

Cylindrical

Operating Temperature Range:

Up to 120 °C

Series:

Rolling Element:

Cylindrical roller bearing

Suffix Description:

E: Increased Load Capacity M1: Solid Brass Cage, Two Piece, Roller Guided

Snap Ring:

Transaction Information:

Transport Package:

Box+Pallet

Service:

OEM Service

Shipping Ways:

DHL / TNT / UPS / ARMEX / FEDEX ,Etc

Country of Origin:

Germany

Quality Control:

ISO9001:2015

Stock:

825 Piece

Production Capacity:

100000pcs/year

Port:

Shanghai/Qingdao/Guangzhou/Hongkong

Payment term:

TT/Western Union/Paypal

Delivery time:

3~5 days

Detailed description

NJ207E.M1.C3 Single Row Cylindrical Roller Bearing 35x72x17 mm

Cylindrical Roller Bearing, NJ207E.M1, 35x72x17 mm, Brass Cage, Single Row, No Seal, Inner Ring-Both Side Separable; No Snap Ring, Relubricatable, C3.

The NJ207E.M1.C3 is a single-row cylindrical bearing with NJ design. The outer ring has two rigid ribs, while the inner ring has one rigid rib. As a result, NJ bearings can support radial forces as well as axial forces in a single direction. This bearing type is used as a support bearing. Support bearings allow axial displacement of the shaft relative to the housing in one direction. The shaft is located axially in the other direction. NJ bearings can also be used as locating bearings by combining them with HJ angle rings (available separately). Locating bearings are used to locate a shaft axially in both directions.

E: Increased Load Capacity

M1: Solid Brass Cage, Two Piece, Roller Guided

Part Number	NJ207E.M1.C3	Package	Carton Box+Pallet
Size:	35x72x17 mm	Material	Bearing steel
Bore diameter (d):	35 mm (1.378 Inch)	Place of Origin	Germany
Outside Diameter (D):	72 mm (2.835 Inch)	Structure	Cylindrical Roller Bearing
Width, outer ring (T):	17 mm (0.669 Inch)	Sealing	No seal
Profile	Complete with Outer and Inner Ring	nG	14100 r/min
Relubricatable	Yes	nB	8100 r/min
Radial internal clearance	C3	Cage	Brass Cage
Precision Grade	P6 P5 P4	Certifications	ISO9001:2015
Number of Row	1	Basic dynamic load rating	59 kN
MOQ	1PCS	Basic static load rating	50 kN
Weight	0.295 KG	Lead Time	3~5 Days
Payment Term	TT or Western Union	Retainer	Yes
Brand Name	As per requirement	Snap Ring	No
Bore Type	Cylindrical	Seperable	Inner Ring-Two Sides
Bore Profile	Straight	Heat Stabilization	Temperatures up to 120 °C
Design	NJ	Fatigue load limit (Pu)	7.7 kN
da min	39 mm	da max	43 mm
Da max	65 mm	dc min	50 mm
ra max	1 mm	Tmin	-30 °C
r min	1.1 mm	Tmax	120 °C
r1 min	1 mm	s	0.7mm
E	64 mm	F	44 mm
D1 min	61 mm	d1	48 mm
Application	gearboxes, agricultural machinery, pumps, compressors, and electric motors.	Other Features	2 Rib Inner Ring, Plain Outer Ring, Cage on Inner Ring OD, High Capacity, Medium Series, X Life Bearing

Please contact Cherry if you are interested in this product:

WhatsApp: +86 13825082601

Mobile: +86 18928876761

Email: [email protected]

Share this product to:

Let more people see your product

How can you buy NJ207E.M1.C3 Single Row Cylindrical Roller Bearing 35x72x17 Mm on the Internet?
High quality NJ207E.M1.C3 ( 0.295 kg Mass, ID: 35 mm OD: 72 mm WD: 17 mm , NJ Series , 1 Rows , C3 Radial Clearance , P6 P5 P4 Accuracy Class , Bearing Steel Material , 59 kN Radial dynamic , 50 kN Radial static ), Just click the button " Contact Now " to mention your purchase Requirement , Quantity and Contact Method of your requested Bearing Item No. NJ207E.M1.C3. then click the button " Send " The web site will make your purchasing information sent to the supplier's mailbox, who will come to contact you upon they get your information at the first time.
