NJ 314 ECM Single Row Cylindrical Roller Bearing 70x150x35 Mm

🔍

NJ 314 ECM

Bore Diameter:70 mm

Outside Diameter:150 mm

Width:35 mm

Weight:3.23 kg

Min. Order:1 Piece

The NJ 314 ECM bearing is a Cylindrical roller beairngs with an inner diameter of 70 mm , an outer diameter of 150 mm, a width of 35 mm. It typically uses P6 P5 P4 grade precision tolerances and features a Brass cage, Bearing Steel rings. It primarily bears Axial/Radial, Its dynamic radial rated load is approximately 236 kN, its static radial rated load is approximately 228 kN. It uses C0 standard radial clearance, Open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Feature: Plain Inner Ring, 2 Rib Outer Ring, Cage on Outer Ring ID

Application: gearboxes, agricultural machinery, pumps, compressors, and electric motors.

Dimensions:

Inside Diameter:

70 mm

Outside Diameter:

150 mm

Thickness:

35 mm

Weight:

3.23 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

236 kN

Static load Capacity, Radial (Cor):

228 kN

Fatigue Load Limit, Radial:

29 kN

Reference speed (Grease rpm):

4800 r/min

Limiting speed (Oil rpm):

5600 r/min

Specifications:

Old Designations:

NJ314ECM

HS Code:

8482500090

Structure:

Cylindrical Roller Bearing

Number of Rows:

Demensions:

70x150x35 mm

Brand:

As Per Requirements

Radial Clearance Trade No.:

Precision Rating:

P6 P5 P4

Vibration:

ZV1/ZV2/ZV3

Load Direction:

Axial/Radial

Bearing Material:

Bearing Steel

Cage Type:

Brass Cage

Cage material:

Brass

Seals Type:

Open

Roller Material:

Bearing Steel

Bore Type:

Cylindrical

Operating Temperature Range:

Up to 120 °C

Series:

Rolling Element:

Cylindrical roller bearing

Suffix Description:

EC: Optimized Internal Design Incorporating More And/Or Larger Rollers And With Modified Roller/End Flange Contact. M: Solid Brass Cage, Two Piece, Roller Guided

Snap Ring:

Transaction Information:

Transport Package:

Box+Pallet

Service:

OEM Service

Shipping Ways:

DHL / TNT / UPS / ARMEX / FEDEX ,Etc

Country of Origin:

Germany

Quality Control:

ISO9001:2015

Stock:

584 Piece

Production Capacity:

100000pcs/year

Port:

Shanghai/Qingdao/Guangzhou/Hongkong

Payment term:

TT/Western Union/Paypal

Delivery time:

3~5 days

Detailed description

NJ 314 ECM Single Row Cylindrical Roller Bearing 70x150x35 mm

Cylindrical Roller Bearing, NJ 314 ECM, 70x150x35 mm, Brass Cage, Single Row, No Seal, No Separable; No Snap Ring, Relubricatable, C0.

Single row cylindrical roller bearings are designed to accommodate high radial loads in combination with high speeds. Having two integral flanges on the outer ring and no flanges on the inner ring, NJ design bearings can accommodate axial displacement in both directions. An important feature is the separable design, which facilitates mounting and enables the bearing components to be interchanged.

EC: Optimized Internal Design Incorporating More And/Or Larger Rollers And With Modified Roller/End Flange Contact.

M: Solid Brass Cage, Two Piece, Roller Guided

Part Number	NJ 314 ECM	Package	Carton Box+Pallet
Size:	70x150x35 mm	Material	Bearing steel
Bore diameter (d):	70 mm (2.756 Inch)	Place of Origin	Germany
Outside Diameter (D):	150 mm (5.906 Inch)	Structure	Cylindrical Roller Bearing
Width, outer ring (T):	35 mm (1.378 Inch)	Sealing	No seal
Profile	Complete with Outer and Inner Ring	Grease Limiting Speed (r/min)	4800 r/min
Relubricatable	Yes	Oil Limiting Speed (r/min)	5600 r/min
Radial internal clearance	C0	Cage	Brass Cage
Precision Grade	P6, P5, P4	Certifications	ISO9001:2015
Number of Row	1	Basic dynamic load rating	236 kN
MOQ	1PCS	Basic static load rating	228 kN
Weight	3.23 KG	Lead Time	3~5 Days
Payment Term	TT or Western Union	Application	Manufacturing Plant, Energy & Mining
Brand Name	As per requirement	Snap Ring	No
Bore Type	Cylindrical	Seperable	No
Bore Profile	Straight	Heat Stabilization	Temperatures up to 120 °C
Retainer	Ye	Other Features	Plain Inner Ring, 2 Rib Outer Ring, Cage on Outer Ring ID
Design	NJ	Number of flanges, outer ring	2
Number of flanges, inner ring	1	Loose flange	None
d1	97.3 mm	D1	125.6 mm
s max	1.8 mm	r1,2 min.	2.1 mm
F	89 mm	r3,4 min.	2.1 mm
da min.	82 mm	da max.	86 mm
Da max.	137.5 mm	Fatigue load limit (Pu)	29 kN
db min	100 mm	ra max	2 mm
ra max	2 mm	kr	0.15 mm
e	0.2 mm	Y	0.6 mm
