NCF1876V (Alt P/N: SL181876) Full Complement Cylindrical Roller Bearing

🔍

NCF1876V

Bore Diameter:380 mm

Outside Diameter:480 mm

Width:46 mm

Weight:19.2 kg

Min. Order:1 Piece

The NCF1876V bearing is a Cylindrical Roller Bearings with an inner diameter of 380 mm , an outer diameter of 480 mm, a width of 46 mm. It typically uses Standard grade precision tolerances and Chrome Steel (Gcr15) rings. Its dynamic radial rated load is approximately 600 (kN), its static radial rated load is approximately 1200 (kN). Open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Equivalent: SL181876

Application: Gearboxes, Hoisting Equipment, Rolling Mills and Machines in the Mining Industry, e.g. tunnelling machines.

Dimensions:

Inside Diameter:

380 mm

Outside Diameter:

480 mm

Thickness:

46 mm

Weight:

19.2 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

600 (kN)

Static load Capacity, Radial (Cor):

1200 (kN)

Reference speed (Grease rpm):

280

Limiting speed (Oil rpm):

530

Specifications:

HS Code:

8482500090

Structure:

Roller Bearing

Number of Rows:

Single

Demensions:

380x480x46

Brand:

Neutral Product

Precision Rating:

Standard

Bearing Material:

Chrome Steel (Gcr15)

Seals Type:

Open

Roller Material:

Chrome Steel (Gcr15)

Bore Type:

Cylindrical

Operating Temperature Range:

-30℃ to 120℃

System of Measurement:

Metric

Series:

NCF

Rolling Element:

Roller

Closure Type:

Open

Transaction Information:

Transport Package:

Standard Export Package

Shipping Ways:

by Sea or Air

Country of Origin:

China

Stock:

100 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

NCF1876V Cylindrical Roller Bearing (Interchange Part No.: SL181876), Single Row, Full Complement, Outer Ring Located with a Snap Ring, High Radial Load Carrying Capacity, Long Service Life.

Size: 380x480x46mm

Bore Diameter (d): 380mm

Outside Diameter (D): 480mm

Width (B): 46mm

Race Material: Chrome Steel

Roller Element Material: Chrome Steel

Cage Design: Full Complement without Cage

Number of Rolling Element Rows: 1

Number of Flanges (Outer Ring): 1

Number of Flanges (Inner Ring): 2

Sealing: Without

Design: Non-Separable

Bore Type: Cylindrical

Operating Temperature: -30°C to 120°C

Precision: Standard

HS Code: 8482500090

Equivalent Prefix for NCF: SL18

Suffixes C: Modified Internal Design

Suffixes V: Version Without Cage (Full Complement)

Part No.	Dimensions (mm)			Basic Load Rating		Speed Limits		Weight	Alt. P/N:
	Bore	Outer	Width	Dynamic	Static	Grease	Oil
	d	D	B	C	Co	rpm
	mm			kN		1 min		Kg
NCF1876V	380	480	46	600	1200	280	530	19.2	SL181876

Single Row Full Complement Cylindrical Roller Bearings are designed to accommodate very high radial loads in combination with moderate speeds. The bearings incorporate a maximum number of rollers as they are not equipped with a cage. Having two integral flanges on the inner ring and one flange on the outer ring, NCF design bearings can accommodate axial displacement in one direction. A retaining ring on the outer ring holds the bearing together. The retaining ring should not be loaded axially during operation.

Common Applications: Gear Drives, Crop Shears, Rolling Mills, General Industrial, Wheel End Planetaries, and etc.

All the bearings we are offering are direct factory price, fast delivery, perfect quality. For more bearings, please feel free to mail us at [email protected] or contact us by Wechat or Whatsapp at +8618062246726.

Share this product to:

Let more people see your product

How can you buy NCF1876V (Alt P/N: SL181876) Full Complement Cylindrical Roller Bearing on the Internet?
High quality NCF1876V ( 19.2 kg Mass, ID: 380 mm OD: 480 mm WD: 46 mm , NCF Series , Single Rows , Standard Accuracy Class , Chrome Steel (Gcr15) Material , 600 (kN) Radial dynamic , 1200 (kN) Radial static ), Just click the button " Contact Now " to mention your purchase Requirement , Quantity and Contact Method of your requested Bearing Item No. NCF1876V. then click the button " Send " The web site will make your purchasing information sent to the supplier's mailbox, who will come to contact you upon they get your information at the first time.
