Luoyang Compact 88-0148-00 Cross Roller Bearing Replacement Supply

🔍

88-0148-00

Bore Diameter:90 mm

Outside Diameter:210 mm

Width:25 mm

Weight:4 kg

Reference FOB Price:US300 ~ 500 / Piece

Min. Order:1 Piece

The 88-0148-00 bearing is a cross roller bearing with an inner diameter of 90 mm , an outer diameter of 210 mm, a width of 25 mm. It typically uses P0, P6, P5, P4, P2 grade precision tolerances and features a Nylon/steel/copper cage, GCr15 balls, GCr15 rings. open type, NBR. together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Application: robotics, machine tools, indexing tables, tool changers, turntables, welding cells, etc.

Dimensions:

Inside Diameter:

90 mm

Outside Diameter:

210 mm

Thickness:

25 mm

Weight:

4 KG

Outer Ring Width:

24.8

Inner Ring Width:

24.8

Limiting speed (Oil rpm):

EP2

Specifications:

HS Code:

8482109000

Structure:

cross roller slewing bearing

Number of Rows:

single row

Demensions:

210*90*25

Brand:

LYMC

Precision Rating:

P0, P6, P5, P4, P2

Bearing Material:

42CrMo/50Mn

Cage material:

Nylon/steel/copper

Seals Type:

open

Seal Material:

NBR

Ball Material:

GCr15

Roller Material:

GCr15

Rolling Element:

steel roller

Gear Options:

non-gear

Transaction Information:

Transport Package:

export wooden cases

Service:

reply within 24 hours

Shipping Ways:

sea, air, express, train

Country of Origin:

China

Quality Control:

iso9001, QC report

Stock:

10 Piece

Production Capacity:

1000 sets/month

Port:

qingdao, shanghai, tianjin, ningbo, guangzhou

Payment term:

fob, cif, exw

Delivery time:

15-30 days

Detailed description

Luoyang compact 88-0148-00 cross roller bearing replacement supply

Type No.:88-0148-00

Material:42CrMo4

Hardness:260-290HB

Ce(outer diameter):210mm

Ci:(inner diameter):90mm

HT(total height):25mm

Dm(raceway diameter):148mm

Fe(outer pitch diameter):187mm

Fi:(inner pitch diameter):112mm

He(outer height):24.8mm

Hi(inner height):24.8mm

Ne(outer hole no.):12-φ14 12-φ9
Ni(inner hole no):12-φ14 12-φ9

weight:4kgs

The slewing ring are delivered lubricated with MOBILUX EP2 or equivalent grease.

slewing rings are used in robotics, machine tools, indexing tables, tool changers, turntables, welding cells, etc.

More types we manufacture:

88-0148-00 88-0178-00 88-0228-00 88-0297-00 88-0445-00

For more information or inquiry, please feel free to contact us!
