LMK6UU Flange Linear Bearings 6x12x19mm
LMK6UU
Bore Diameter:6 mm
Outside Diameter:12 mm
Width:19 mm
Weight:0.018 kg
The LMK6UU bearing is a Linear Bearing with an inner diameter of 6 mm , an outer diameter of 12 mm, a width of 19 mm. It typically uses P0 to P2 grade precision tolerances and Double Seal type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.
×
Detailed description
LMK6UU Flange Linear Bearings 6x12x19mm
About Product :
| Model No. |
LMK6UU |
| part name | Linear Bearing |
| Dimension | 6x12x19mm |
| Weight | 0.018kg |
| Material | Chrome Steel |
| Precision Grade | P0 to P2 |
| Bearing Service | Customized |
| Cage | Steel, Brass, Carbon |
| Packing | Coloured Single Box + carton + Pallet |
| Seal stype | Double Seal |
| Source | China Bearing Factory |
| Contact Person | Ms. phoebe Ye |
| Skype | Skype: fskbearing2 |
| Mail: [email protected] |
Payment & Delivery:
Packaging Details:Packing for Miniature Ball Bearing
1.Industrial Packing: a)Plastic Tube+Carton+Pallet b)Plastic Bag+Kraft Paper+Carton+Pallet
2.Commercial Packing a)Plastic Bag+Color Box+Carton+Pallet
3.According to the Requirement of Customers.
The advantages of linear bearing:
1.Adjustable pressure. ZERO interval standard.
2. Reparing and cost for wear and tear parts can exchangeable.
3. Lower sensitive style of dust.
4. Do not need grind surface to install rail.
5. Both guide rail and slide board can move.
6. Higher speed noise volume is lower.
7. Best price.
Application:
1)Agriculture,
2)Light textile,
3)Mining,
4)Food &beverage,
5)Pharmaceutical,
6)Chemical processing,
7)Printing,
8)Dyeing,
9)Airport,
10)Air-conditioning,
11)Various kinds of conveying and rolling devices.
Same series:
| Bearing No. | ID | OD | Length | Flang Size | Static | Dynamic | ||
| Standard | dr | D | L | D1 | H | PCD | C (N) | C0 (N) |
| LMK 6 | 6 | 12 | 19 | 28 | 5 | 20 | 206 | 265 |
| LMK 8S | 8 | 15 | 17 | 32 | 5 | 24 | 176 | 225 |
| LMK 8 | 8 | 15 | 24 | 32 | 5 | 24 | 265 | 402 |
| LMK 10 | 10 | 19 | 29 | 40 | 6 | 29 | 373 | 549 |
| LMK 12 | 12 | 21 | 30 | 42 | 6 | 32 | 412 | 598 |
| LMK 13 | 13 | 23 | 32 | 43 | 6 | 33 | 510 | 775 |
| LMK 16 | 16 | 28 | 37 | 48 | 6 | 38 | 775 | 1180 |
| LMK 20 | 20 | 32 | 42 | 54 | 8 | 43 | 863 | 1370 |
| LMK 25 | 25 | 40 | 59 | 62 | 8 | 51 | 980 | 1570 |
| LMK 30 | 30 | 45 | 64 | 74 | 10 | 60 | 1570 | 2750 |
| LMK 35 | 35 | 52 | 70 | 82 | 10 | 67 | 1670 | 3140 |
| LMK 40 | 40 | 60 | 80 | 96 | 13 | 78 | 2160 | 4020 |
| LMK 50 | 50 | 80 | 100 | 116 | 13 | 98 | 3820 | 7940 |
| LMK 60 | 60 | 90 | 110 | 134 | 18 | 112 | 4710 | 10000 |
