LM60UU OP Linear Ball Bushing 60mm × 90mm × 110mm
The LM60UU OP bearing is a Linear Bearing with an inner diameter of 60 mm , an outer diameter of 90 mm, a width of 110 mm. It typically uses ABEC-1, ABEC-3 , ABEC-5 , ABEC-9 grade precision tolerances and Open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.
LM60UU OP Linear Ball Bushing 60mm × 90mm × 110mm
About Product :
|
Model Number |
LM60UU OP |
|
Part Name |
Linear Motion Bearing |
| Structure | Linear Ball Bearings |
| Type | Open Type |
|
Number of Ball Rows |
Six Row |
|
Material |
Gcr15 Chrome Steel |
|
Precision Rating |
P0 P6 P5 P4 P2 |
| Vibration and Noise | Z0V0 / Z1V1 / Z2V2 / Z3V3 |
| Cage | Steel Cage / Nylon Cage |
| Service | OEM |
| Dimension | 60mm × 90mm × 110mm |
| Weight | 2kg |
| HS Code | 8482990000 |
| Original Country Show | CHINA |
|
Contact Person |
Ms. Ellie Liao |
| Skype | fskbearing1 |
| [email protected] |
LM linear bearing:
LM3UU,LM4UU,LM5UU,LM6UU,LM8UU,LM8S,LM10UU,
LM12UU,LM13UU,LM16UU,LM20UU,LM25UU,LM30UU,LM35UU,
LM40UU,LM50UU,LM60UU, LM80UU,LM100UU
LME linear bearing:
LME3UU,LME4UU,LME5UU,LME6UU,LME8UU,LME8S,LME10UU,
LME12UU,LME13UU,LME16UU,LME20UU,LME25UU,LME30UU,
LME35UU,LME40UU,LME50UU,LME60UU, LME80UU,LME100UU
LMB linear bearing:
LMB4UU,LMB6UU,LMB8UU,LMB10UU,LMB12UU,LMB16UU,
LMB24UU,LMB32UU
LM Open linear bearing:LM10OPUU,LM12OPUU,LM13OPUU,LM16OPUU,
LM20OPUU,
LM25OPUU,LM3OOPU,LM35OPUU,LM40OPUU,LM50OPUU,
LM60OPUU,LM80OPUU,LM100OPUU
Linear Motion Bearings List:
| Designation | Major dimensions(mm) | Ratings load | |||||
| LM-OP | Number of ball rows | dr | D | L | Dynamic CN | Static CoN | |
| Weight | |||||||
| (g) | |||||||
| LM10-OP | 4 | 30 | 10 | 19 | 29 | 372 | 549 |
| LM12-OP | 5 | 31.5 | 12 | 21 | 30 | 510 | 784 |
| LM13-OP | 5 | 43 | 13 | 23 | 32 | 510 | 784 |
| LM16-OP | 5 | 69 | 16 | 28 | 37 | 774 | 1180 |
| LM20-OP | 6 | 87 | 20 | 32 | 42 | 882 | 1370 |
| LM25-OP | 6 | 220 | 25 | 40 | 59 | 980 | 1570 |
| LM30-OP | 6 | 250 | 30 | 45 | 64 | 1570 | 2740 |
| LM35-OP | 6 | 390 | 35 | 52 | 70 | 1670 | 3140 |
| LM40-OP | 6 | 585 | 40 | 60 | 80 | 2160 | 4020 |
| LM50-OP | 6 | 1580 | 50 | 80 | 100 | 3820 | 7940 |
| LM60-OP | 6 | 2000 | 60 | 90 | 110 | 4700 | 10000 |
| LM80-OP | 6 | 4420 | 80 | 120 | 140 | 7350 | 16000 |
| LM100-OP | 6 | 8600 | 100 | 150 | 175 | 14120 | 34800 |
| LM120-OP | 8 | 14900 | 120 | 180 | 200 | 16400 | 40000 |
| LM150-OP | 8 | 20150 | 150 | 210 | 240 | 21100 | 54300 |
LM60UU OP Open Type Linear Ball Bushing
60mm × 90mm × 110mm, Get Cheap Price from China Steering Bearing Factory Now !
