LM249747NW-LM249710D Tapered Roller Double Row

🔍

LM249747NW-LM249710D

Bore Diameter:254 mm

Outside Diameter:347,66 mm

Width:101,60 mm

Weight:0.27 kg

Min. Order:2 Piece

The LM249747NW-LM249710D bearing is a Tapered Roller Bearings with an inner diameter of 254 mm , an outer diameter of 347,66 mm, a width of 101,60 mm. It typically uses p0/p6/p5/p4/p2 grade precision tolerances and It primarily bears Radial Bearing, Its dynamic radial rated load is approximately 64600 N, its static radial rated load is approximately 63100 N. It uses C0 C2 C3 C4 C5 standard radial clearance, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Feature: temperature resistance,strong stability,wear-resistant

Application: Automotive, rolling mill, mining, metallurgical, skateboard etc.

Dimensions:

Inside Diameter:

254 mm

Outside Diameter:

347,66 mm

Thickness:

101,60 mm

Weight:

0.27 KG

Chamfer (R):

3.556 mm

Cone Width (B):

50.8 mm

Cup Width (C):

69.850 mm

Chamfer (r):

1.5 mm

Performance Data:

Dynamic load Capacity, Radial (Cr):

64600 N

Static load Capacity, Radial (Cor):

63100 N

Specifications:

HS Code:

8482102000

Structure:

roller Bearing

Number of Rows:

Double

Demensions:

254*347.66*101.60

Brand:

Z&K/Neutral / OEM

Radial Clearance Trade No.:

C0 C2 C3 C4 C5

Precision Rating:

p0/p6/p5/p4/p2

Vibration:

Z1V1 Z2V2 Z3V3

Load Direction:

Radial Bearing

Bearing Material:

Bearing Steel

Cage Type:

Sheet metal

Operating Temperature Range:

Tmin -15 °C to Tmin 80 °C

Transaction Information:

Transport Package:

Single Box, Plastic Barrel, Carton, Tray

Shipping Ways:

Sea, land and air transport

Country of Origin:

China

Stock:

10 Piece

Production Capacity:

10000PCS/Year

Port:

Guangzhou

Payment term:

TT/PAPAL/WESTERN UNION

Delivery time:

7-15

Detailed description

LM249747NW-LM249710D Tapered Roller Double Row
LM249747NW-LM249710D Tapered Roller Double Row
Bearing NO.:	LM249747NW-LM249710D	MOQ:	1PCS
Material	Bearing steel	Cone Width (mm)	50.8
Bore Diameter(inch):	10	Double Cup Width (mm)	69.85
Outer Diameter(inch):	13.6875	Bearing Width across Cones (mm)	101.6
Height(inch):	4	Cone Backface "To Clear" Radius1 (mm)	3.556
Masa(lbs):	54.67	Cup Backface "To Clear" Radius2 (mm)	1.5
Inner (d) (mm)	254	Cone Backface Backing Diameter (mm)	272
Outer (D) (mm)	347,66	Cup Frontface Backing Diameter (mm)	334
Width (B) (mm)	101,6	Cone Backface Clearance (mm)	6.1
Mass(kg)	24.8	Effective Center Location3 (mm)	5.6
Row number	Single	Dynamic Radial Rating (One-Row, 90 million revolutions)4(N)	159000
Factor8	1.76	Dynamic Radial Rating (Two-Row, 1 million revolutions)5(N)	1070000
ISO Factor9	0.33	Dynamic Radial Rating (Two-Row, 90 million revolutions)6	277000
ISO Factor10	2.03	Dynamic Thrust Rating (90 million revolutions)7(N)	90500
Applicable Industries:	Manufacturing Plant,Home Use, Printing Shops,Construction works,Advertising Company	Contact Bonnie:	Email:[email protected]
Applicable Industries:		Contact Bonnie:	Email:[email protected]
