L624549 Tapered Roller Bearings With Low Voice

🔍

L624549

Bore Diameter:120.65 mm

Width:21.433 mm

Min. Order:2 Piece

The L624549 bearing is a Tapered Roller Bearings with an inner diameter of 120.65 mm , a width of 21.433 mm. features a Steel cage, Steel balls, steel rings. It primarily bears Radial Bearing, Its dynamic radial rated load is approximately 105000, its static radial rated load is approximately 206000. It uses C0 C2 C3 C4 C5 standard radial clearance, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Feature: Reducer, Papermaking Machinery, Railway Vehicle

Application: Automotive, rolling mill, mining, metallurgical, skateboard etc.

Dimensions:

Inside Diameter:

120.65 mm

Thickness:

21.433 mm

Chamfer (R):

1.5

Cone Width (B):

21.433

Performance Data:

Dynamic load Capacity, Radial (Cr):

105000

Static load Capacity, Radial (Cor):

206000

Specifications:

HS Code:

8482102000

Structure:

roller Bearing

Number of Rows:

Single

Demensions:

120.65*0*21.433

Radial Clearance Trade No.:

C0 C2 C3 C4 C5

Vibration:

Z1V1 Z2V2 Z3V3

Load Direction:

Radial Bearing

Cage material:

Steel

Ball Material:

Steel

Roller Material:

steel

Series:

L624500

Cone Number:

L624549

Transaction Information:

Transport Package:

Single Box, Plastic Barrel, Carton, Tray

Shipping Ways:

Sea, land and air transport

Country of Origin:

China

Stock:

10 Piece

Production Capacity:

1000PCS/Year

Port:

Guangzhou

Payment term:

TT/PAPAL/WESTERN UNION

Delivery time:

7-15

Detailed description

L624549 Tapered Roller Bearings With Low Voice
L624549 Tapered Roller Bearings With Low Voice
Bearing NO.:	L624549	MOQ:	1PCS
Series:	L624500	Sample:	Available
Cone Part NO.:	L624549	Material:	Bearing steel
Cup Part NO.:	0	Aa (mm):	0.5
Bore (mm)d:	120.65	Ab (mm):	2.5
Cup Outer Diameter(mm)D:	0	db(mm):	129
Cone Width(mm)B:	21.433	da(mm):	127
Dynamic Thrust Rating(C90(2))N:	47500	R(mm):	1.5
Dynamic load rating (C₉₀)N:	27300	a:	8.4
Dynamic load rating (C₁)N:	105000	K:	1.34
Static Radial Rating(CO)N:	206000	G1:	195
Dynamic Thrust Rating(Ca₉₀)N:	20300	G2:	139
Category:	Tapered Roller Bearing	Cg:	0.151
Applicable Industries:	Manufacturing Plant,Home Use, Printing Shops,Construction works,Advertising Company	Contact Bonnie:
Applicable Industries:		Contact Bonnie:

Share this product to:

Let more people see your product

How can you buy L624549 Tapered Roller Bearings With Low Voice on the Internet?
High quality L624549 ( ID: 120.65 mm WD: 21.433 mm , L624500 Series , Single Rows , C0 C2 C3 C4 C5 Radial Clearance , 105000 Radial dynamic , 206000 Radial static ), Just click the button " Contact Now " to mention your purchase Requirement , Quantity and Contact Method of your requested Bearing Item No. L624549. then click the button " Send " The web site will make your purchasing information sent to the supplier's mailbox, who will come to contact you upon they get your information at the first time.
