L Shape RKS.21 0841 Slewing Ring With Size 95073456mm

🔍

RKS.21 0841

Bore Diameter:734 mm

Outside Diameter:950 mm

Width:56 mm

Weight:68 kg

Reference FOB Price:US100 ~ 500 / Piece

Min. Order:1 Piece

The RKS.21 0841 bearing is a four point contact ball bearing with an inner diameter of 734 mm , an outer diameter of 950 mm, a width of 56 mm. It typically uses P0, P6, P5, P4, P2 grade precision tolerances and features a Nylon cage, GCr15 balls, GCr15 rings. open type, NBR. together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Application: industrial equipment, heavy construction machinery

Dimensions:

Inside Diameter:

734 mm

Outside Diameter:

950 mm

Thickness:

56 mm

Weight:

68 KG

Outer Ring Width:

Inner Ring Width:

Limiting speed (Oil rpm):

EP2

Specifications:

HS Code:

8482109000

Structure:

four point contact ball bearing

Number of Rows:

single row

Demensions:

950*734*56mm

Brand:

LYMC

Precision Rating:

P0, P6, P5, P4, P2

Bearing Material:

42CrMo/50Mn

Cage material:

Nylon

Seals Type:

open

Seal Material:

NBR

Ball Material:

GCr15

Roller Material:

GCr15

Gear Options:

external gear

Transaction Information:

Transport Package:

export wooden cases

Service:

reply within 24 hours

Shipping Ways:

sea, air, express, train

Country of Origin:

China

Quality Control:

iso9001

Stock:

1000 Piece

Production Capacity:

10000

Port:

qingdao, shanghai, tianjin, ningbo, guangzhou

Payment term:

fob, cif, exw

Delivery time:

15-30 days

Detailed description

L shape RKS.21 0841 slewing ring with size 950*734*56mm

De(OD):950mm

Di(ID):734mm

Bi:798mm

Fe:885m

Ne:18

Fi:762mm

Ni:18

m(module):8

z(teeth no.):117

D:936mm

Total height:56mm

weight:68kgs

Material:42CrMo/50Mn

Rolling elements:steel ball

Operating tempereature:-40°C +150°C

Load direction:Radial bearing

Raceway hardness:55~62HRC

Inner and outer ring modulation hardness:229-268HB

High operational efficiency:compact design

packaging:wooden box

shipment: sea or air

L-shape bearings only to be used in compression.

Steel : high quality steel, XC 45 improved

Lubrication : L’Shape slewing bearings are pre-lubricated with a lithium soap, EP additives and a consistency of 2

Bolting class : 10.9 recommended

Grease nipples : four equally grease nipples (M8X1.00) (G)

High quality raceways hardening L’Shape slewing bearings with special holes or without holes for attachment bolts

if you are interested in China factory RKS.21 0841 slewing ring with size 950*734*56mm, please contact us freely.
