K89452-M Axial Cylindrical Roller And Cage Assemblies

🔍

K89452-M

Bore Diameter:260 mm

Outside Diameter:480 mm

Width:44 mm

Weight:36.8 kg

Min. Order:1 Piece

The K89452-M Cylindrical roller thrust bearings are specifically designed for applications requiring heavy axial loads and stringent positioning accuracy. Classic applications include heavy-duty vertical lathe tables, marine propeller shaft thrust devices, large gearboxes, wind turbine main gearboxes, rolling mill pressing mechanisms, and crane slewing bearings.

The K89452-M bearing is a Axial cylindrical roller and cage assemblies, double row with an inner diameter of 260 mm , an outer diameter of 480 mm, a width of 44 mm. GCr15SiMn rolling mlement. Its dynamic axial rated load is approximately 3597340 N, its static axial rated load is approximately 14689138 N. together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

260 mm

Outside Diameter:

480 mm

Thickness:

44 mm

Weight:

36.8 KG

Dynamic load Capacity, axial:

3597340 N

Static load Capacity, axial:

14689138 N

Fatigue Load Limit, Axial:

1147499 N

Reference speed (Grease rpm):

223

Limiting speed (Oil rpm):

743

Specifications:

Structure:

Cylindrical Roller Thrust Bearings

Number of Rows:

Two

Cage Type:

M = Brass Cage

Rolling Mlement Material:

GCr15SiMn

Operating Temperature:

-20 to 120 °C

System of Measurement:

Metric

Series:

K894 series (K894..-M)

Rolling Element:

cylindrical rollers

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

K89452-M bearings ( 260 mm x 480 mm x 44 mm) have the advantages of extremely high axial load capacity, high rigidity, compact axial structure, and a detachable design for easy installation, and are therefore widely used in the Machine tool worktables, extruders, differentials, wind power equipment, and oil drilling machinery.

Part Number	K89452-M
Bearing Type	Axial cylindrical roller and cage assemblies, double row
Series	K894 series (K894..-M)
Cage	M = Brass Cage
Rows NO.	Two
Weight [lb]	81.1293
C_a Axial Dynamic [lbf]	808682
C_0a Axial static [lbf]	3302118
C_ua Axial Fatigue [lbf]	257957
n_B Speed ratings (grease) [rpm]	223
n_G Speed ratings (oil) [rpm]	743
Dw [inch]	1.7323
D_c [inch]	18.8976
D_c1 [inch]	10.2362
E_b Raceway [inch]	11.2598
E_a Raceway [inch]	18.4252

The K89452-M Cylindrical roller thrust bearings mainly consist of a shaft ring, a housing ring, cylindrical rollers, and a cage assembly. The rollers are arranged radially, forming a line contact load-bearing structure.

The advantages of cylindrical roller thrust bearings include extremely high axial load capacity, excellent rigidity, and a low coefficient of friction. Optimized roller end faces and flanges can accommodate slight eccentricity and impact loads, while also featuring a compact structure and high rotational accuracy.

Share this product to:

Let more people see your product

How can you buy K89452-M Axial Cylindrical Roller And Cage Assemblies on the Internet?
High quality K89452-M ( 36.8 kg Mass, ID: 260 mm OD: 480 mm WD: 44 mm , K894 series (K894..-M) Series , Two Rows ), Just click the button " Contact Now " to mention your purchase Requirement , Quantity and Contact Method of your requested Bearing Item No. K89452-M. then click the button " Send " The web site will make your purchasing information sent to the supplier's mailbox, who will come to contact you upon they get your information at the first time.
