K89322-M Axial Cylindrical Roller And Cage Assemblies

🔍

K89322-M

Bore Diameter:110 mm

Outside Diameter:190 mm

Width:15 mm

Weight:1.83 kg

Min. Order:1 Piece

The K89322-M Cylindrical roller thrust bearings are specifically designed for applications requiring heavy axial loads and stringent positioning accuracy. Classic applications include heavy-duty vertical lathe tables, marine propeller shaft thrust devices, large gearboxes, wind turbine main gearboxes, rolling mill pressing mechanisms, and crane slewing bearings.

The K89322-M bearing is a Axial cylindrical roller and cage assemblies, double row with an inner diameter of 110 mm , an outer diameter of 190 mm, a width of 15 mm. GCr15SiMn rolling mlement. Its dynamic axial rated load is approximately 499607 N, its static axial rated load is approximately 1869304 N. together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

110 mm

Outside Diameter:

190 mm

Thickness:

15 mm

Weight:

1.83 KG

Dynamic load Capacity, axial:

499607 N

Static load Capacity, axial:

1869304 N

Fatigue Load Limit, Axial:

164886 N

Reference speed (Grease rpm):

773

Limiting speed (Oil rpm):

1877

Specifications:

Structure:

Cylindrical Roller Thrust Bearings

Number of Rows:

Two

Cage Type:

M = Brass Cage

Rolling Mlement Material:

GCr15SiMn

Operating Temperature:

-20 to 120 °C

System of Measurement:

Metric

Series:

K893 series (K893..-M)

Rolling Element:

cylindrical rollers

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

K89322-M bearings ( 110 mm x 190 mm x 15 mm) have the advantages of extremely high axial load capacity, high rigidity, compact axial structure, and a detachable design for easy installation, and are therefore widely used in the Machine tool worktables, extruders, differentials, wind power equipment, and oil drilling machinery.

Part Number	K89322-M
Bearing Type	Axial cylindrical roller and cage assemblies, double row
Series	K893 series (K893..-M)
Cage	M = Brass Cage
Rows NO.	Two
Weight [lb]	4.0344
C_a Axial Dynamic [lbf]	112311
C_0a Axial static [lbf]	420219
C_ua Axial Fatigue [lbf]	37066
n_B Speed ratings (grease) [rpm]	773
n_G Speed ratings (oil) [rpm]	1877
Dw [inch]	0.5906
D_c [inch]	7.4803
D_c1 [inch]	4.3307
E_b Raceway [inch]	4.7244
E_a Raceway [inch]	7.2835

The K89322-M Cylindrical roller thrust bearings mainly consist of a shaft ring, a housing ring, cylindrical rollers, and a cage assembly. The rollers are arranged radially, forming a line contact load-bearing structure.

The advantages of cylindrical roller thrust bearings include extremely high axial load capacity, excellent rigidity, and a low coefficient of friction. Optimized roller end faces and flanges can accommodate slight eccentricity and impact loads, while also featuring a compact structure and high rotational accuracy.
