K81256-M Axial Cylindrical Roller And Cage Assemblies

🔍

K81256-M

Bore Diameter:280 mm

Outside Diameter:380 mm

Width:32 mm

Weight:11.5 kg

Min. Order:1 Piece

The K81256-M Cylindrical roller thrust bearings are specifically designed for applications requiring heavy axial loads and stringent positioning accuracy. Classic applications include heavy-duty vertical lathe tables, marine propeller shaft thrust devices, large gearboxes, wind turbine main gearboxes, rolling mill pressing mechanisms, and crane slewing bearings.

The K81256-M bearing is a Axial cylindrical roller and cage assemblies, Single row with an inner diameter of 280 mm , an outer diameter of 380 mm, a width of 32 mm. GCr15SiMn rolling mlement. Its dynamic axial rated load is approximately 1455419 N, its static axial rated load is approximately 5598113 N. together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

280 mm

Outside Diameter:

380 mm

Thickness:

32 mm

Weight:

11.5 KG

Dynamic load Capacity, axial:

1455419 N

Static load Capacity, axial:

5598113 N

Fatigue Load Limit, Axial:

463022 N

Reference speed (Grease rpm):

320

Limiting speed (Oil rpm):

833

Specifications:

Structure:

Cylindrical Roller Thrust Bearings

Number of Rows:

One

Cage Type:

M = Brass Cage

Rolling Mlement Material:

GCr15SiMn

Operating Temperature:

-20 to 120 °C

System of Measurement:

Metric

Series:

K812 series (K812..-M)

Rolling Element:

cylindrical rollers

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

K81256-M bearings ( 280 mm x 380 mm x 32 mm) have the advantages of extremely high axial load capacity, high rigidity, compact axial structure, and a detachable design for easy installation, and are therefore widely used in the Machine tool worktables, extruders, differentials, wind power equipment, and oil drilling machinery.

Part Number	K81256-M
Bearing Type	Axial cylindrical roller and cage assemblies, Single row
Series	K812 series (K812..-M)
Cage	M = Brass Cage
Rows NO.	One
Weight [lb]	25.3529
C_a Axial Dynamic [lbf]	327178
C_0a Axial static [lbf]	1258455
C_ua Axial Fatigue [lbf]	104087
n_B Speed ratings (grease) [rpm]	320
n_G Speed ratings (oil) [rpm]	833
Dw [inch]	1.2598
D_c [inch]	14.9606
D_c1 [inch]	11.0236
E_b Raceway [inch]	11.8504
E_a Raceway [inch]	14.6063

The K81256-M Cylindrical roller thrust bearings mainly consist of a shaft ring, a housing ring, cylindrical rollers, and a cage assembly. The rollers are arranged radially, forming a line contact load-bearing structure.

The advantages of cylindrical roller thrust bearings include extremely high axial load capacity, excellent rigidity, and a low coefficient of friction. Optimized roller end faces and flanges can accommodate slight eccentricity and impact loads, while also featuring a compact structure and high rotational accuracy.
