K34008XP0 Thin-section Ball Bearing 340x356x8mm
The K34008AR0/CP0/XP0 bearing is a Thin-section Ball Bearing with an inner diameter of 340 mm , an outer diameter of 356 mm, a width of 8 mm. It typically uses P0/P6/P5 grade precision tolerances and Open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.
Bearing model: K34008AR0/CP0/XP0 Thin-section Ball bearing
Inner Diameter ( ID ):340 mm
Outer Diameter (OD):356 mm
Width/Height: 8 mm
Material:chrome steel(GCR15)
Weight:0.38 kg
Number of Row: single row
Seals type: Open
K34008AR0 The thin-section angular contact bearings are designed for supporting axial load .They can also used to support radial or combining radial traction .But this type can’t solely used to sustain moment load or reverse radical forces. They always appeared in pairs.
K34008CP0 The thin-section radial contact ball bearing primarily designed for deep groove ball bearing to sustain heavy pressure. The basic design intention is not only to support radical load , but also can sustain middle axial load, rotary load and moment load.
K34008XP0 Thin-section four-point contact bearing is the ideal choice for supporting moment heavy pressure. It successfully satisfies the four points contact between raceway and steel ball in order to support moment load and reversing axial load. Although it can be applied in light load.
