JG110XP0 Thin Section Ball Bearing (Size: 11x13x1 Inch)
The JG110XP0 bearing is a Thin Section Bearings with an inner diameter of 11 inch , an outer diameter of 13 inch, a width of 1 inch. It typically uses Standard grade precision tolerances and features a Brass cage, Chrome Steel (Gcr15) balls, Sealed type, Rubber. together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.
Application: Rotary Tables, Turntables, Robotics, Packaging Equipment, and etc.
JG110XP0 Thin Section Ball Bearing, Four Point Contact, Type X, Single Row, Inch Size, Lightweight, Low friction, and High Running Accuracy.
Size: 11x13x1 Inch
Bore: 11 Inch
Outside Diameter: 13 Inch
Width: 1 Inch
Type : Four Point Contact ( Type X)
Race Material: Chrome Steel
Ball Material: Chrome Steel
Cage Material: Brass
Number of Rows: 1
Enclosure: Sealed (Rubber Seals on Both Sides)
Precision: Standard
Operating Temperature: -30°C to 120°C
HS Code: 8482103000
|
JG Series |
||||||||||||||
|
Part No. |
Dimensions (Inch) |
Capacities (lbs) |
Limiting Speeds (rpm) |
Torque Max. No Load (in-lb) |
Weight |
|||||||||
|
Size |
Land Diameters |
Dynamic |
Static |
|||||||||||
|
Bore |
Outside Dia. |
Width |
L1 |
L2 |
Radial |
Thrust |
Moment |
Radial |
Thrust |
Moment |
lbs. |
|||
|
JG110XP0 |
11 |
13 |
1 |
11.554 |
12.602 |
12739 |
20180 |
57347 |
19700 |
49250 |
118200 |
160 |
38 |
8.6 |
The X-Type, or 4-point contact, ball bearing is ideal for moment loading. X-Type bearings are designed with gothic arch raceways creating 4 contact points between the balls and the raceways. This design is excellent for moment loading and reversing axial loading. The X-Type bearing can be used for other light loading conditions, but is not recommended in place of the C- or A-Type bearing for pure radial loads.
Thin section bearings were primarily developed for applications that have crucial space limitations. Therefore, they are recognized to be a perfect fit for work holding devices such as indexing, rotary tables, and turntables. They also offer a friction-less solution for articulating parts such as robotic arms or other joints like elbows. Different types of thin section bearings are extensively utilized in diverse mechanisms, including data storage, robotics, medical imaging, packaging equipment, satellite systems, and optical & targeting systems.
All the bearings we are offering are direct factory price, fast delivery, perfect quality. For more bearings, please feel free to mail us at [email protected] or contact us by Wechat or Whatsapp at +8618062246726.
