HM911244 High Speed Tapered Roller Bearings For Machinery

🔍

HM911244

Bore Diameter:59.987 0 30.925 mm

Width:30.925 mm

Min. Order:2 Piece

The HM911244 bearing is a Tapered Roller Bearings with an inner diameter of 59.987 0 30.925 mm , a width of 30.925 mm. features a Steel cage, Steel balls, steel rings. It primarily bears Radial Bearing, Its dynamic radial rated load is approximately 198000, its static radial rated load is approximately 183000. It uses C0 C2 C3 C4 C5 standard radial clearance, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Feature: Reducer, Papermaking Machinery, Railway Vehicle

Application: Automotive, rolling mill, mining, metallurgical, skateboard etc.

Dimensions:

Inside Diameter:

59.987 0 30.925 mm

Thickness:

30.925 mm

Chamfer (R):

3.6

Cone Width (B):

30.925

Chamfer (r):

3.3

Performance Data:

Dynamic load Capacity, Radial (Cr):

198000

Static load Capacity, Radial (Cor):

183000

Specifications:

HS Code:

8482102000

Structure:

roller Bearing

Number of Rows:

Single

Demensions:

59.987*0*30.925

Radial Clearance Trade No.:

C0 C2 C3 C4 C5

Vibration:

Z1V1 Z2V2 Z3V3

Load Direction:

Radial Bearing

Cage material:

Steel

Ball Material:

Steel

Roller Material:

steel

Series:

HM911200

Cone Number:

HM911244

Transaction Information:

Transport Package:

Single Box, Plastic Barrel, Carton, Tray

Shipping Ways:

Sea, land and air transport

Country of Origin:

China

Stock:

10 Piece

Production Capacity:

1000PCS/Year

Port:

Guangzhou

Payment term:

TT/PAPAL/WESTERN UNION

Delivery time:

7-15

Detailed description

HM911244 High Speed Tapered Roller Bearings For Machinery
HM911244 High Speed Tapered Roller Bearings For Machinery
Bearing NO.:	HM911244	MOQ:	1PCS
Series:	HM911200	Material:	Bearing steel
Cone Part NO.:	HM911244	Ab (mm):	0.2
Bore (mm)d:	59.987	Aa (mm):	3.8
Cup Outer Diameter(mm)D:	0	db(mm):	90
Cone Width(mm)B:	30.925	da (mm):	74
Row number:	Single	R(mm):	3.6
Cage:	Steel	a:	7.9
Dynamic Radial Rating(C90(2))N:	89200	e:	0.82
Dynamic load rating (C₉₀)N:	51200	K:	0.71
Dynamic load rating (C₁)N:	198000	G1:	56.4
Static Radial Rating(CO)N:	183000	G2:	16.5
Dynamic Thrust Rating(Ca₉₀)N:	71900	Cg:	0.0842
Applicable Industries:	Auto Building Material Shops, Manufacturing Plant, Machinery Repair Shops	Contact Bonnie:	Email:[email protected]
Applicable Industries:		Contact Bonnie:	Email:[email protected]

Share this product to:

Let more people see your product

How can you buy HM911244 High Speed Tapered Roller Bearings For Machinery on the Internet?
High quality HM911244 ( ID: 59.987 0 30.925 mm WD: 30.925 mm , HM911200 Series , Single Rows , C0 C2 C3 C4 C5 Radial Clearance , 198000 Radial dynamic , 183000 Radial static ), Just click the button " Contact Now " to mention your purchase Requirement , Quantity and Contact Method of your requested Bearing Item No. HM911244. then click the button " Send " The web site will make your purchasing information sent to the supplier's mailbox, who will come to contact you upon they get your information at the first time.

- 32218JR Single Row Tapered Roller Bearings
- 32218JR Tapered roller bearings (Grease) Lubrication Speed: 2400 r/min (Oil) Lubrication Speed: 3200
- SET424 555S/552A Tapered Roller Bearing 57.15x123.825x38.1mm
- SET424 555S/552A Tapered Roller Bearing 57.15x123.825x38.1mm Air Compressor Bearing Inner Bore(Metric):57.15 mm
- 12749-12710 Tapered Roller Bearings for Machinery
- 12749-12710This bearing construction accommodates combined loads and provides low friction during operation.
- 6576-6535B Single Row High Speed Tapered Roller Bearings
