HH224334/HH224310 (HH224334XA) Tapered Roller Bearing (Size: 3.936x8.375x5.625 Inch)

🔍

HH224334/HH224310 (HH224334XA)

Bore Diameter:99.974 mm

Outside Diameter:212.725 mm

Width:142.875 mm

Weight:22.81 kg

Min. Order:1 Piece

The HH224334/HH224310 (HH224334XA) bearing is a Tapered Roller Bearings with an inner diameter of 99.974 mm , an outer diameter of 212.725 mm, a width of 142.875 mm. It typically uses Standard grade precision tolerances and features a Steel cage, Chrome Steel (Gcr15) rings. together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Application: Gearboxes, Hoisting Equipment, Rolling Mills and Machines in the Mining Industry, e.g. tunnelling machines.

Dimensions:

Inside Diameter:

99.974 mm

Outside Diameter:

212.725 mm

Thickness:

142.875 mm

Weight:

22.81 KG

Chamfer (R):

3.6

Chamfer (r):

0.8

Specifications:

HS Code:

8482500090

Structure:

Roller Bearing

Number of Rows:

Double

Demensions:

99.974x212.725x142.875

Brand:

Neutral Product

Precision Rating:

Standard

Bearing Material:

Chrome Steel (Gcr15)

Cage material:

Steel

Roller Material:

Chrome Steel (Gcr15)

Bore Type:

Cylindrical

Operating Temperature Range:

-40℃ to 120℃

System of Measurement:

Inch

Rolling Element:

Roller

Cone Number:

HH224334

Cup Number:

HH224310

Transaction Information:

Transport Package:

Standard Export Package

Shipping Ways:

by Sea or Air

Country of Origin:

China

Stock:

100 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

HH224334/HH224310 (HH224334XA) Tapered Roller Bearing, Matched Bearing Assembly, Indirect Mount.

Size (Inner Dia x Outer Dia x Total Width): 3.936x8.375x5.625 Inch (99.974x212.725x142.875 mm)

Cone Part No.: HH224334

Cup Part No.: HH224310

Inner Spacer Part No.: HH224334XA

Mini Operating Temperature:-40 °C

Max Operating Temperature:120 °C

HH224334/HH224310 (HH224334XA) Tapered Roller Bearing
Type:	2TS-IM
Cone Part Number:	HH224334
Cup Part Number:	HH224310
Inner Spacer Part Number	HH224334XA
Bearing Weight (kg)	22.81
Main Dimensions:
	inch	mm
d-Bore:	3.936	99.974
D-Cup Outer Diameter:	8.375	212.725
T - Bearing Width Across Cones	5.625	142.875
C - Cup Width	4.625	117.475
Bearing Type:	Roller
Ring Material:	Chrome Steel
Roller Material:	Chrome Steel
Cage Material:	Stamped Steel
Spacer Material:	Steel
Precision:	Standard Precision
Country of Origin:	China
HS Code:	8482500090

2TS-IM assemblies are comprised of two single-row bearings with an inner and outer ring spacer. In some applications, a shoulder in the bearing housing replaces the outer ring spacer.

Design Attributes:

Steel spacers are used to create Bench End Play (BEP) or Preload (BPL) in the bearing assembly.

Available with or without spacers.

Spacers preset during manufacture.

Applications: gear reduction units, gearboxes, hoisting equipment, rolling mills and industrial machines.

All the bearings we are offering are direct factory price, fast delivery, perfect quality. For more bearings, please feel free to mail us at [email protected] or contact us by Wechat or Whatsapp at +8618062246726.
