HC6000-C-2HRS-TVH-L207-C3>V Deep Groove Ball Bearings 2HRS Design
The HC6000-C-2HRS-TVH-L207-C3>V Miniature ball bearings are widely used in precision equipment with stringent space and precision requirements, such as: medical devices (dental handpieces, miniature pumps), precision instruments (flow meters, encoders), robots (miniature joints), optical equipment (camera focusing mechanisms), miniature motors, and aerospace precision instruments.
The HC6000-C-2HRS-TVH-L207-C3>V bearing is a Deep groove ball bearings 2HRS design with an inner diameter of 10 mm , an outer diameter of 26 mm, a width of 8 mm. It typically uses Class6 (P6) grade precision tolerances and GCr15SiMn rings, Ceramic balls rolling mlement. Its dynamic radial rated load is approximately 5271 N, its static radial rated load is approximately 1841 N. It uses C3 standard radial clearance, 2HRS = Lip seal on both sides type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.
HC6000-C-2HRS-TVH-L207-C3>V bearings ( 10 mm x 26 mm x 8 mm) have the advantages of Small size, light weight, low friction, high speed, suitable for precision rotation in tiny spaces, and are therefore widely used in the Precision instruments, medical equipment, drones, robots, motors and various miniature transmission devices.
| Part Number | HC6000-C-2HRS-TVH-L207-C3>V |
| Reference From | FAG HC6000-C-2HRS-TVH-L207-C3>V |
| Bearing Type | Deep groove ball bearings 2HRS design |
| Series | HC60..-C-2HRS-TVH |
| Internal design | C = Generation C |
| Ball material | Ceramic balls |
| Sealing | 2HRS = Lip seal on both sides |
| Cage | TVH = Glass fibre reinforced polyamide, ball-guided |
| Radial internal clearances | C3 |
| Heat stabilization | SN = (up to 120 °C) |
| Lubricant | L207 = High-temperature, low noise, grease L069 |
| Design | HC = Hybrid bearing, ball ceramic, rings made of steel |
| Weight [lb] | 0.035 |
| Cr Radial Dynamic [lbf] | 1184 |
| C0r Radial static [lbf] | 413 |
| Cur Radial Fatigue [lbf] | 19 |
| nG Limiting speed [rpm] | 28470 |
| Operating temperature - T(min) [°C] | -30 |
| Operating temperature - T(max) [°C] | 100 |
| d φ Inside [inch] | 0.394 |
| D Φ Outside [inch] | 1.024 |
| B Width [inch] | 0.315 |
| d2 [inch] | 0.539 |
| D2 [inch] | 0.909 |
| r(min.) [inch] | 0.012 |
| D1 [inch] | 0.840 |
| d1 [inch] | 0.577 |
| Mounting dimensions | |
| da(min.) [inch] | 0.472 |
| Da(max.) [inch] | 0.945 |
| ra(max.) [inch] | 0.012 |
| Coefficient - F0 [inch] | 11.9 |
The HC6000-C-2HRS-TVH-L207-C3>V Miniature ball bearings primarily consist of thin-walled inner and outer rings (precision machined), tiny steel balls (typically less than 3mm in diameter), and a cage (stamped steel or one-piece plastic). The most common type is the deep groove ball bearing, available in open, dust-covered, or sealed configurations, with inner diameters typically ranging from 1mm to 10mm.
Miniature ball bearings are small and lightweight, making them suitable for extremely compact spaces. They offer high rotational accuracy, reaching P4 level or higher, with smooth operation and low frictional torque. They exhibit significant low noise and low vibration characteristics, and some models feature a dustproof design to effectively prevent the intrusion of tiny particles, resulting in a long service life.
