GK80-DO Rod End (Size:80x180x231mm)

🔍

GK80-DO

Bore Diameter:80 mm

Outside Diameter:180 mm

Width:231 mm

Weight:8.7 kg

Min. Order:1 Piece

The GK80-DO bearing is a Rod Ends with an inner diameter of 80 mm , an outer diameter of 180 mm, a width of 231 mm. Its dynamic radial rated load is approximately 400, its static radial rated load is approximately 620. together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Application: Hydraulic cylinders, Vehicle suspensions, Articulated joints, Heavy duty linkage pivots, High load hitch assemblies

Dimensions:

Inside Diameter:

80 mm

Outside Diameter:

180 mm

Thickness:

231 mm

Weight:

8.7 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

400

Static load Capacity, Radial (Cor):

620

Specifications:

Structure:

Rod Ends

Demensions:

80x180x231

Brand:

Neutral Product

Bearing Material:

Chrome Steel (Gcr15)

Series:

GK-DO

Transaction Information:

Transport Package:

Standard Export Package

Shipping Ways:

by Sea or Air

Country of Origin:

China

Stock:

100 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

GK80-DO Hydraulic Rod End

Size: 80x180x231mm

Bore Diameter Bearing (d): 80mm
Outer Eye Diameter (d2): 180mm
Total Length Welding Head (L4): 231mm

GK80-DO Rod End for hydraulic components. It is made up of a radial spherical plain bearing GE..E or GE..ES and rod end housing. Fixed in housing by snap rings, rod end with weldable steel and phosphated, with circular welding face, requiring maintenance, sliding contact surface: steel/steel. It has characteristics of large load capability, easy mounting and dismounting.

Applications:
1. Cars
2. Trucks
3. Lawn Tractors
4. Boats
5. Industrial Machines
6. Aircraft Control Systems

GK80-DO Hydraulic Rod End

Bearing Number

Boundary dimensions

Weight (kg)

L4
max

rs min

a°
≈

GK80-DO

105

180

141

231

8.7

All the bearings we are offering are direct factory price, fast delivery, perfect quality. For more bearings, please feel free to mail us at [email protected], or contact us by Wechat or Whatsapp at +8618062246726.

Share this product to:

Let more people see your product

How can you buy GK80-DO Rod End (Size:80x180x231mm) on the Internet?
High quality GK80-DO ( 8.7 kg Mass, ID: 80 mm OD: 180 mm WD: 231 mm , GK-DO Series , Chrome Steel (Gcr15) Material , 400 Radial dynamic , 620 Radial static ), Just click the button " Contact Now " to mention your purchase Requirement , Quantity and Contact Method of your requested Bearing Item No. GK80-DO. then click the button " Send " The web site will make your purchasing information sent to the supplier's mailbox, who will come to contact you upon they get your information at the first time.
