FPCG2500 Bore 25 Inch, Imperial Open Type C, Radial Contact Ball Bearings
The FPCG2500 Thin-section deep-groove ball bearings are primarily used in applications where space is limited, weight reduction is required, and loads are moderate. Typical applications include industrial robots (such as joints and end-effectors), semiconductor manufacturing equipment, medical imaging equipment (CT scanner gantries), optical trackers, radar antennas, packaging machinery spindles, and lightweight aerospace transmission mechanisms. They are capable of supporting both radial and bidirectional axial loads.
The FPCG2500 bearing is a Inch Open Type C Radial Contact Ball Bearings with an inner diameter of 25 inch , an outer diameter of 27 inch, a width of 1 inch. It typically uses ISO Class NORMAL / ABEC-1 grade precision tolerances and AISI 52100 Steel rings, AISI 52100 Steel rolling mlement. Its dynamic radial rated load is approximately 14595 N, its static radial rated load is approximately 42680 N. Open (No seal) type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.
FPCG2500 bearings ( 25 inch x 27 inch x 1 inch) have the advantages of Extremely compact, lightweight design, composite load-bearing capacity, high rigidity, and flexible installation, and are therefore widely used in the Robots, semiconductor equipment, medical instruments, radar antennas, and aerospace precision mechanisms.
| Part Number | FPCG2500 |
| Bore | Cylindrical |
| Balls | standard 1/2" balls |
| Bearing Type | Inch Open Type C Radial Contact Ball Bearings |
| Cage | Brass; snapover separator |
| Series | FPCG SERIES 1" X 1" |
| Race Width Tolerance | +0.000 -0.005" |
| Temperature - T(min) [°C] | -30 |
| Temperature - T(max) [°C] | 110 |
| Seal type | Open (No seal) |
| Manufacturer Part Code | FPCG 2500 |
| Units | Inch |
| Load | radial, axial, moment and combined loads |
| Rolling Element Type | Balls |
| Ball Material | AISI 52100 Steel |
| Rolling Element Material | AISI 52100 Steel |
| Precision Class | ISO Class NORMAL / ABEC-1 |
| Equivalent | KAYDON KDN.KG250CP0 SILVERTHIN SG250CP0 SKF FPCG2500 FAG L10WA2500 NSK NBC63525 INA CSCG250 SSB RG250CP0 NTN KRG250 |
| Interchangeable | SKF FPCG2500 |
| Rows NO. | One |
| L1 Land Diameter [inch] | 25.742 |
| L2 Land Diameter [inch] | 26.258 |
| Fillet radius (Note 2) max | 0.080" |
| RADIAL DYNAMIC [lbf] | 14595 |
| RADIAL STATIC [lbf] | 42680 |
| APPROX WEIGHT [lb] | 19.5 |
The FPCG2500 Thin-section deep groove ball bearings mainly consist of a thin-walled inner ring, a thin-walled outer ring, steel balls, and a cage. Their cross-sectional dimensions are constant and extremely thin, typically conforming to ISO 12240 standards, and are available in open or sealed configurations.
Thin-section deep groove ball bearings utilize a thin-walled constant cross-section design, resulting in lightweight construction and a small footprint, significantly reducing the overall weight and size of equipment. They can simultaneously withstand radial and bidirectional axial loads, exhibiting low friction and high-speed characteristics, and are easy to install, making them suitable for light to medium load conditions.
