F689ZZ Flanged Miniature Bearing Size 9x17x5mm

🔍

F689ZZ

Bore Diameter:9 mm

Outside Diameter:17 mm

Width:5 mm

Min. Order:1 Piece

The F689ZZ bearing is a Deep Groove Ball Bearings with an inner diameter of 9 mm , an outer diameter of 17 mm, a width of 5 mm. It typically uses P0 grade precision tolerances and features a Steel cage, Chrome Steel (Gcr15) balls, It primarily bears Radial, Its dynamic radial rated load is approximately 1324 (N), its static radial rated load is approximately 667 (N). Shielded type, Steel. together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Application: small power tools, printers, computer hard drives, model toys, and various precision instruments and electronic equipment

Dimensions:

Inside Diameter:

9 mm

Outside Diameter:

17 mm

Thickness:

5 mm

Performance Data:

Dynamic load Capacity, Radial (Cr):

1324 (N)

Static load Capacity, Radial (Cor):

667 (N)

Reference speed (Grease rpm):

Limiting speed (Oil rpm):

Specifications:

HS Code:

8482102000

Structure:

Ball Bearing

Number of Rows:

Single

Demensions:

9x17x5

Brand:

Neutral Product

Precision Rating:

Load Direction:

Radial

Bearing Material:

Chrome Steel (Gcr15)

Cage material:

Steel

Seals Type:

Shielded

Seal Material:

Steel

Ball Material:

Chrome Steel (Gcr15)

Operating Temperature Range:

-20℃ to 120℃

System of Measurement:

Metric

Series:

F680

Rolling Element:

Ball

Transaction Information:

Transport Package:

Standard Export Package

Shipping Ways:

by Sea or Air

Country of Origin:

China

Stock:

100 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

F689ZZ Miniature Deep Groove Ball Bearing with Flange, Double Shielded, Single Row, High Speed, Low Noise.

Size: 9x17x5mm

Inner Diameter (d): 9mm

Outer Diameter (D): 17mm

Width (t): 5mm

Inner Race and Outer Race Material: Chrome Steel

Rolling Element Material: Chrome Steel

Cage Material: Steel

Seal Type: Shielded

Shield Material: Steel

Precision: P0

Number of Row: Single

Load Direction: Radial

Working Temperature:- 20 to 120°C

HS Code: 8482102000

Bearing Part No.	Dimensions (mm)					Basic Load Ratings		Limiting Speed (rev/min)		Weight (g)
Bearing Part No.	Bore (d)	OD (D)	Width (t)	Flange Dia (D1)	Flange Width (t1)	Cr (N)	Cor (N)	Grease	Oil	Weight (g)
F689ZZ	9	17	5	19	1.1	1324	667	36	43	4.87

Miniature bearings are widely used in different of applications, including small power tools, printers, computer hard drives, model toys, and various precision instruments and electronic equipment that demand compact and efficient bearing solutions.

All the bearings we are offering are direct factory price, fast delivery, perfect quality. For more bearings, please feel free to mail us at [email protected] or contact us by Wechat or Whatsapp at +8618062246726.
