External Toothed EB2.30.1249.400-1SPPN Double Row Ball Bearing Slewing Ring

🔍

EB2.30.1249.400-1SPPN

Bore Diameter:1085 mm

Outside Diameter:1476 mm

Width:110 mm

Weight:502 kg

Reference FOB Price:US100 ~ 1500 / Piece

Min. Order:1 Piece

The EB2.30.1249.400-1SPPN bearing is a double row slewing ball bearing with an inner diameter of 1085 mm , an outer diameter of 1476 mm, a width of 110 mm. It typically uses P0, P6, P5, P4, P2 grade precision tolerances and features a Nylon/steel/copper cage, GCr15 balls, GCr15 rings. open type, NBR. together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Application: Cranes, Aerial lifts, Excavators, Wind turbines, Utility derricks, Log loaders and feller bunchers, Grapples, Mining equipment

Dimensions:

Inside Diameter:

1085 mm

Outside Diameter:

1476 mm

Thickness:

110 mm

Weight:

502 KG

Outer Ring Width:

101

Inner Ring Width:

101

Limiting speed (Oil rpm):

EP2

Specifications:

HS Code:

8482109000

Structure:

double row slewing ball bearing

Number of Rows:

double row

Demensions:

1476*1085*110

Brand:

LYMC

Precision Rating:

P0, P6, P5, P4, P2

Bearing Material:

42CrMo/50Mn/45#/custom

Cage material:

Nylon/steel/copper

Seals Type:

open

Seal Material:

NBR

Ball Material:

GCr15

Roller Material:

GCr15

Rolling Element:

steel ball

Gear Options:

external gear

Transaction Information:

Transport Package:

export wooden cases

Service:

reply within 24 hours, oem service, design service, technical support

Shipping Ways:

sea, air, express, train

Country of Origin:

China

Quality Control:

iso9001, QC report

Stock:

100 Piece

Production Capacity:

100pc/month

Port:

shanghai, qingdao, tianjin, ningbo, guangzhou

Payment term:

fob, cif, exw

Delivery time:

15-45days

Detailed description

External toothed EB2.30.1249.400-1SPPN double row ball bearing slewing ring

material:42crmo/50mn/45#/custom

structure:double row slewing ball bearing

gear option:external gear, internal gear, non gear

raceway hardness:55-62HRC

outer ring dia(De):1476mm

inner ring dia(Di):1085mm

thickness/width(H):110mm

Mounting hole dia(Fe):1350mm

Mounting hole dia(Fi):1150mm

outer ring width/thickness(He):101mm

inner ring width/thickness(Hi):101mm

Mass:502kgs

More types for you:

EB2.22.0383.400-1RPPN
EB2.25.0475.400-1RPPN
EB2.25.0575.400-1RPPN
EB2.25.0980.400-1RPPN
EB2.28.1117.400-1SPPN
EB2.28.1215.400-1RPPN
EB2.28.1215.401-1RPPN
EB2.30.1249.400-1SPPN

Luoyang MC Bearing Technology Co.,Ltd (LYMC),who is manufacture located in bearing zone, focus on Slewing bearing, cross roller bearing and pinion,Dia from 50mm-8000mm, Our team with technical and full experience in the bearing industry.

Double row ball slewing bearings
This kind of bearings can support high static loads with simple structures. They are mainly used in situations with variation load position and direction and continuously rotating. Main applications of this kind of bearings are deck hoisting, mining and material handling etc.

Packaging:

1.Filling with anti-rust oil
2.Corved with Plastic paper
3.Corved with kraft paper
4.Corved with Blue tie
5.Put in wooden box

Delivery time:

within 7 working days with stock(standard slewing bearing)

within 35-45 working days without stock(non-standard slewing bearing)

Payment term:T/T

If any interesteed items or inquiry, please feel free to contact us. All inquiry will be replied within 24 hours.
