E.900.25.00.B Slewing Bearing With Outer Gear 898x655x80mm

🔍

E.900.25.00.B

Bore Diameter:655 mm

Outside Diameter:898 mm

Width:80 mm

Weight:128 kg

The E.900.25.00.B bearing is a Slewing bearing / Slewing ring with an inner diameter of 655 mm , an outer diameter of 898 mm, a width of 80 mm. It typically uses P0 grade precision tolerances and Sealed type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

655 mm

Outside Diameter:

898 mm

Thickness:

80 mm

Weight:

128 KG

Specifications:

Structure:

Four-ponit contact ball slewing Bearing

Precision Rating:

Bearing Material:

C45N/50Mn/42CrMo

Seals Type:

Sealed

Transaction Information:

Payment term:

30% T/T in Advance, the balance 70%TT before shipp

Delivery time:

Detailed description

Bearing model:E.900.25.00.B Four-ponit contact ball slewing Bearing

Inner Diameter ( ID ) :655 mm

Outer diameter (OD) :898 mm

Width/Height : 80 mm

Outer Gear Teeth

Moudle: M=9

NO. of teeth: Z=98

Pressure Angle: a=20°

Modification coefficient: X=0

Material :42CrMo/50Mn/C45N

Seals type: Rubber/Fluororubber seals

Lubrication: Grease

It is widely used in hoister transportation, mining, architecture, harbor machinery, shipping mechanism, radar machinery of high accuracy, and large-scale rotary devices on aspect of missile launcher.

Share this product to:

Let more people see your product

How can you buy E.900.25.00.B Slewing Bearing With Outer Gear 898x655x80mm on the Internet?
High quality E.900.25.00.B ( 128 kg Mass, ID: 655 mm OD: 898 mm WD: 80 mm , P0 Accuracy Class , C45N/50Mn/42CrMo Material ), Just click the button " Contact Now " to mention your purchase Requirement , Quantity and Contact Method of your requested Bearing Item No. E.900.25.00.B. then click the button " Send " The web site will make your purchasing information sent to the supplier's mailbox, who will come to contact you upon they get your information at the first time.
