D-3637-A Double-acting Thrust Tapered Roller Bearing Brass Cage

🔍

D-3637-A

Bore Diameter:380 mm

Outside Diameter:560 mm

Width:130 mm

Weight:96 kg

Min. Order:1 Piece

The D-3637-A Thrust angular contact ball bearings are mainly suitable for applications requiring high speed, low friction, and simultaneous axial and certain radial loads, such as fluid control valves, machine tool worktables and spindles, and rotary tables in the oil and gas drilling industry.

The D-3637-A bearing is a Double-acting thrust tapered roller bearing with an inner diameter of 380 mm , an outer diameter of 560 mm, a width of 130 mm. It typically uses PN (ABEC-1) grade precision tolerances and bearing steel rings, bearing steel rolling mlement. its static axial rated load is approximately 10192925 N. together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

380 mm

Outside Diameter:

560 mm

Thickness:

130 mm

Weight:

96 KG

Static load Capacity, axial:

10192925 N

Specifications:

Structure:

Thrust Tapered Roller Bearings

Number of Rows:

Two

Precision Rating:

PN (ABEC-1)

Bearing Material:

bearing steel

Cage Type:

brass cage

Rolling Mlement Material:

bearing steel

Bore Type:

Cylindrical bore

Operating Temperature:

-30 to 110 °C

System of Measurement:

Inch

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

D-3637-A bearings ( 380 mm x 560 mm x 130 mm) have the advantages of Composite load, high speed, high rigidity, and are therefore widely used in the rotary tables of oil and gas drilling rigs.

Part Number	D-3637-A
Design type	TTDFLK 1: Two single tapered outer races; One flat inner race; Inner-ring bore keyway (optional); One outer-ring spacer with oil slots
Bearing Type	Double-acting thrust tapered roller bearing
Interchangeable	TIMKEN D-3637-A
Manufacturer Part Code	D-3637-A
Cage	brass cage
Units	Inch
Tolerance class	PN (ABEC-1)
Thrust Race Number	Double
Cage type	MB
C_0a Axial Static [lbf]	2291369
Ca1 Dynamic (1 Million Revolutions) [lbf]	510788
Ca90 Dynamic (90 Million Revolutions) [lbf]	132400
d φ Inside [inch]	14.9606
D_o [inch]	22.0472
D_m [inch]	21.2120
T Width [inch]	5.1181
B [inch]	1.2598
r Fillet Radius [inch]	0.1181
R (Max) Shaft Fillet Radius [inch]	0.1102
d_a Mounting dimensions [inch]	16.5354
D_b Mounting dimensions [inch]	20.4370
f Keyway Dimensions [inch]	1.7717
r_k Keyway Dimensions [inch]	0.3937
Weight [lb]	211.6416

The D-3637-A Thrust angular contact ball bearings are mainly composed of precision-ground steel balls, hardened and ground steel raceways, and a brass (or bronze) cage. Their core characteristic is their ability to simultaneously withstand axial thrust loads and a certain amount of radial load, and they also feature low friction, quiet operation, and suitability for high-speed operation.

Share this product to:

Let more people see your product

How can you buy D-3637-A Double-acting Thrust Tapered Roller Bearing Brass Cage on the Internet?
High quality D-3637-A ( 96 kg Mass, ID: 380 mm OD: 560 mm WD: 130 mm , Two Rows , PN (ABEC-1) Accuracy Class , bearing steel Material ), Just click the button " Contact Now " to mention your purchase Requirement , Quantity and Contact Method of your requested Bearing Item No. D-3637-A. then click the button " Send " The web site will make your purchasing information sent to the supplier's mailbox, who will come to contact you upon they get your information at the first time.

D-3637-A Double-acting Thrust Tapered Roller Bearing Brass Cage
