CSXB060 CSEB060 CSCB060 Thin-section Ball Bearing
The CSXB060 CSEB060 CSCB060 bearing is a Thin-section Ball Bearing with an inner diameter of 6 inch , an outer diameter of 6.625 inch, a width of 0.3125 inch. It typically uses P0/P6/P5 grade precision tolerances and Open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.
Bearing model: CSXB060 CSEB060 CSCB060 Thin-section Ball bearing
Inner Diameter (ID):6 inch
Outer Diameter (OD):6.625 inch
Width/Height: 0.3125 inch
Material:chrome steel(GCR15)
Weight:0.2 kg
Number of Row: single row
Seals type: Open
CSCB060 The thin-section radial contact ball bearing primarily designed for deep groove ball bearing to sustain heavy pressure. The basic design intention is not only to support radical load , but also can sustain middle axial load, rotary load and moment load.
CSXB060 Thin-section four-point contact bearing is the ideal choice for supporting moment heavy pressure. It successfully satisfies the four points contact between raceway and steel ball in order to support moment load and reversing axial load. Although it can be applied in light load.
CSEB060 The thin-section angular contact bearings are designed for supporting axial load .They can also used to support radial or combining radial traction .But this type can’t solely used to sustain moment load or reverse radical forces. They always appeared in pairs.
