CRBH7013AC2 High Rigidity Crossed Roller Bearings Open Type With Separator

🔍

CRBH7013AC2

Bore Diameter:70 mm

Outside Diameter:100 mm

Width:13 mm

Weight:0.38 kg

Min. Order:1 Piece

The CRBH7013AC2 Crossed roller bearings are suitable for high-precision, high-rigidity, and space-constrained rotary applications. Classic applications include industrial robot joints and positioners, CNC machine tool rotary tables and indexing heads, medical CT scanner rotating frames, radar antenna rotation mechanisms, precision measuring instruments, and aerospace simulation rotary tables.

The CRBH7013AC2 bearing is a High Rigidity Crossed Roller Bearings Open type with separator with an inner diameter of 70 mm , an outer diameter of 100 mm, a width of 13 mm. It typically uses P0 (ISO Class NORMAL / ABEC-1) grade precision tolerances and 50Mn,42CrMo rings, GCr15 rolling mlement. It primarily bears radial, thrust and moment, Its dynamic radial rated load is approximately 20100 N, its static radial rated load is approximately 27700 N. It uses C2 standard radial clearance, Open type type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

70 mm

Outside Diameter:

100 mm

Thickness:

13 mm

Weight:

0.38 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

20100

Static load Capacity, Radial (Cor):

27700

Reference speed (Grease rpm):

882

Limiting speed (Oil rpm):

1765

Specifications:

Structure:

Crossed Roller Bearings

Number of Rows:

One

Radial Clearance Trade No.:

Precision Rating:

P0 (ISO Class NORMAL / ABEC-1)

Load Direction:

radial, thrust and moment

Bearing Material:

50Mn,42CrMo

Seals Type:

Open type

Rolling Mlement Material:

GCr15

Bore Type:

Cylindrical

Operating Temperature:

-20 to 120 °C

System of Measurement:

Metric

Series:

CRBH..A

Rolling Element:

cylindrical rollers

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

30 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

CRBH7013AC2 bearings ( 70 mm x 100 mm x 13 mm) have the advantages of The rollers are arranged in a cross pattern, allowing them to withstand radial, axial, and overturning moments simultaneously. They offer high rigidity and rotational accuracy while compact and space-saving design, and easy installation, and are therefore widely used in the Industrial robots, CNC machine tools, medical equipment, precision measuring instruments and aerospace.

Part Number	CRBH7013AC2
Bearing Type	High Rigidity Crossed Roller Bearings Open type with separator
Mounting holes	No
Type	CRBH..A
Seal Type	Open type
Bore Type	Cylindrical
Rolling Element Type	cylindrical rollers
Oil holes	Outer ring has an oil groove and two oil holes
Manufacturer Part Code	CRBH 7013 A C2
Load	radial, thrust and moment
Interchangeable	IKO CRBH7013AC2
Units	Metric
Rows NO.	One
Rolling Element Material	GCr15
Inner/Outer Ring Material	50Mn,42CrMo
Lubrication	grease
Accuracy class	P0 (ISO Class NORMAL / ABEC-1)
Guidance of cylindrical roller	with separator
Temperature - T(min) [°C]	-20
Temperature - T(max) [°C]	120
Shaft diameter [inch]	2.756
d φ Inside [inch]	2.756
D Φ Outside [inch]	3.937
B Width [inch]	0.512
r min Chamfer [inch]	0.024
da Mounting dimensions [inch]	2.992
Da Mounting dimensions [inch]	3.701
n_B Reference speed (grease) [r/min]	882
n_G Limiting speed (oil) [r/min]	1765
C_r Radial Dynamic [lbf]	4518
C_0r Radial Static [lbf]	6226
Internal Clearance	C2
Radial internal clearances - C2	min: 15 µm , max: 30 µm
m Bearing Weight [kg]	0.38
Similar Model	CRBH 7013 A C2 P6 CRBH 7013 A C2 P5 CRBH 7013 A C2 P4 CRBH 7013 A C2 P2

The CRBH7013AC2 Crossed roller bearings consist of inner and outer rings, cylindrical rollers, spacers, and seals. The rollers are arranged at 90° intervals within a V-shaped raceway, allowing for multi-directional load bearing even in a single row.

Crossed roller bearings can simultaneously withstand radial loads, bidirectional axial loads, and overturning moments. They possess extremely high rigidity and rotational accuracy, and their compact structure saves installation space, simplifying machine tool design.
