CRBH 4510 A UU C1 P2 Sealed High Rigidity Crossed Roller Bearings Two Sides Sealed Type With Separator

🔍

CRBH 4510 A UU C1 P2

Bore Diameter:45 mm

Outside Diameter:70 mm

Width:10 mm

Weight:0.16 kg

Min. Order:1 Piece

The CRBH 4510 A UU C1 P2 Crossed roller bearings are suitable for high-precision, high-rigidity, and space-constrained rotary applications. Classic applications include industrial robot joints and positioners, CNC machine tool rotary tables and indexing heads, medical CT scanner rotating frames, radar antenna rotation mechanisms, precision measuring instruments, and aerospace simulation rotary tables.

The CRBH 4510 A UU C1 P2 bearing is a Sealed High Rigidity Crossed Roller Bearings Two sides sealed type with separator with an inner diameter of 45 mm , an outer diameter of 70 mm, a width of 10 mm. It typically uses P2 (ISO Class 2 / ABEC-9) grade precision tolerances and 50Mn,42CrMo rings, GCr15 rolling mlement. It primarily bears radial, thrust and moment, Its dynamic radial rated load is approximately 8860 N, its static radial rated load is approximately 11300 N. It uses C1 standard radial clearance, UU = Two sides sealed type, Special synthetic rubber. together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

45 mm

Outside Diameter:

70 mm

Thickness:

10 mm

Weight:

0.16 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

8860

Static load Capacity, Radial (Cor):

11300

Reference speed (Grease rpm):

1043

Specifications:

Structure:

Crossed Roller Bearings

Number of Rows:

One

Radial Clearance Trade No.:

Precision Rating:

P2 (ISO Class 2 / ABEC-9)

Load Direction:

radial, thrust and moment

Bearing Material:

50Mn,42CrMo

Seals Type:

UU = Two sides sealed

Seal Material:

Special synthetic rubber

Rolling Mlement Material:

GCr15

Bore Type:

Cylindrical

Operating Temperature:

-20 to 110 °C

System of Measurement:

Metric

Series:

CRBH..AUU

Rolling Element:

cylindrical rollers

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

30 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

CRBH 4510 A UU C1 P2 bearings ( 45 mm x 70 mm x 10 mm) have the advantages of The rollers are arranged in a cross pattern, allowing them to withstand radial, axial, and overturning moments simultaneously. They offer high rigidity and rotational accuracy while compact and space-saving design, and easy installation, and are therefore widely used in the Industrial robots, CNC machine tools, medical equipment, precision measuring instruments and aerospace.

Part Number	CRBH 4510 A UU C1 P2
Bearing Type	Sealed High Rigidity Crossed Roller Bearings Two sides sealed type with separator
Mounting holes	No
Type	CRBH..AUU
Seal Type	UU = Two sides sealed
Seal Material	Special synthetic rubber
Bore Type	Cylindrical
Rolling Element Type	cylindrical rollers
Oil holes	Outer ring has an oil groove and two oil holes
Manufacturer Part Code	CRBH4510AUUC1P2
Load	radial, thrust and moment
Interchangeable	IKO CRBH 4510 A UU C1 P2
Units	Metric
Rows NO.	One
Rolling Element Material	GCr15
Inner/Outer Ring Material	50Mn,42CrMo
Lubrication	ALVANIA EP grease 2 (pre-packed)
Accuracy class	P2 (ISO Class 2 / ABEC-9)
Guidance of cylindrical roller	with separator
Temperature - T(min) [°C]	-20
Temperature - T(max) [°C]	110
Shaft diameter [inch]	1.772
d φ Inside [inch]	1.772
D Φ Outside [inch]	2.756
B Width [inch]	0.394
r min Chamfer [inch]	0.012
da Mounting dimensions [inch]	2.028
Da Mounting dimensions [inch]	2.500
n_B Reference speed (grease) [r/min]	1043
C_r Radial Dynamic [lbf]	1991
C_0r Radial Static [lbf]	2540
Internal Clearance	C1
Radial internal clearances - C1	min: 0 µm , max: 10 µm
m Bearing Weight [kg]	0.16

The CRBH 4510 A UU C1 P2 Crossed roller bearings consist of inner and outer rings, cylindrical rollers, spacers, and seals. The rollers are arranged at 90° intervals within a V-shaped raceway, allowing for multi-directional load bearing even in a single row.

Crossed roller bearings can simultaneously withstand radial loads, bidirectional axial loads, and overturning moments. They possess extremely high rigidity and rotational accuracy, and their compact structure saves installation space, simplifying machine tool design.
