CRBC 6013 UU T1 Sealed Standard Crossed Roller Bearings With Cage

🔍

CRBC 6013 UU T1

Bore Diameter:60 mm

Outside Diameter:90 mm

Width:13 mm

Weight:0.33 kg

Min. Order:1 Piece

The CRBC 6013 UU T1 Crossed roller bearings are suitable for high-precision, high-rigidity, and space-constrained rotary applications. Classic applications include industrial robot joints and positioners, CNC machine tool rotary tables and indexing heads, medical CT scanner rotating frames, radar antenna rotation mechanisms, precision measuring instruments, and aerospace simulation rotary tables.

The CRBC 6013 UU T1 bearing is a Sealed Standard Crossed Roller Bearings With cage with an inner diameter of 60 mm , an outer diameter of 90 mm, a width of 13 mm. It typically uses P0 (ISO Class NORMAL / ABEC-1) grade precision tolerances and 50Mn,42CrMo rings, GCr15 rolling mlement. It primarily bears radial, thrust and moment, Its dynamic radial rated load is approximately 11600 N, its static radial rated load is approximately 14600 N. It uses T1 standard radial clearance, UU = Two sides sealed type, Special synthetic rubber. together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

60 mm

Outside Diameter:

90 mm

Thickness:

13 mm

Weight:

0.33 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

11600

Static load Capacity, Radial (Cor):

14600

Reference speed (Grease rpm):

800

Specifications:

Structure:

Crossed Roller Bearings

Number of Rows:

One

Radial Clearance Trade No.:

Precision Rating:

P0 (ISO Class NORMAL / ABEC-1)

Load Direction:

radial, thrust and moment

Bearing Material:

50Mn,42CrMo

Seals Type:

UU = Two sides sealed

Seal Material:

Special synthetic rubber

Rolling Mlement Material:

GCr15

Bore Type:

Cylindrical

Operating Temperature:

-20 to 120 °C

System of Measurement:

Metric

Series:

CRBC..UU

Rolling Element:

cylindrical rollers

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

30 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

CRBC 6013 UU T1 bearings ( 60 mm x 90 mm x 13 mm) have the advantages of The rollers are arranged in a cross pattern, allowing them to withstand radial, axial, and overturning moments simultaneously. They offer high rigidity and rotational accuracy while compact and space-saving design, and easy installation, and are therefore widely used in the Industrial robots, CNC machine tools, medical equipment, precision measuring instruments and aerospace.

Part Number	CRBC 6013 UU T1
Bearing Type	Sealed Standard Crossed Roller Bearings With cage
Mounting holes	No
Type	CRBC..UU
Seal Type	UU = Two sides sealed
Seal Material	Special synthetic rubber
Bore Type	Cylindrical
Rolling Element Type	cylindrical rollers
Oil holes	No
Manufacturer Part Code	CRBC6013UUT1
Load	radial, thrust and moment
Interchangeable	IKO CRBC 6013 UU T1
Units	Metric
Rows NO.	One
Rolling Element Material	GCr15
Inner/Outer Ring Material	50Mn,42CrMo
Lubrication	grease
Accuracy class	P0 (ISO Class NORMAL / ABEC-1)
Guidance of cylindrical roller	With cage
Temperature - T(min) [°C]	-20
Temperature - T(max) [°C]	120
Shaft diameter [inch]	2.362
d φ Inside [inch]	2.362
D Φ Outside [inch]	3.543
B Width [inch]	0.512
r min Chamfer [inch]	0.024
da Mounting dimensions [inch]	2.520
Da Mounting dimensions [inch]	3.189
n_B Reference speed (grease) [r/min]	800
C_r Radial Dynamic [lbf]	2607
C_0r Radial Static [lbf]	3282
Internal Clearance	T1
Radial internal clearances - T1	min: -10 µm , max: 0 µm
m Bearing Weight [kg]	0.33

The CRBC 6013 UU T1 Crossed roller bearings consist of inner and outer rings, cylindrical rollers, spacers, and seals. The rollers are arranged at 90° intervals within a V-shaped raceway, allowing for multi-directional load bearing even in a single row.

Crossed roller bearings can simultaneously withstand radial loads, bidirectional axial loads, and overturning moments. They possess extremely high rigidity and rotational accuracy, and their compact structure saves installation space, simplifying machine tool design.
