CRBC 15030 UU Sealed Standard Crossed Roller Bearings With Cage

🔍

CRBC 15030 UU

Bore Diameter:150 mm

Outside Diameter:230 mm

Width:30 mm

Weight:5.3 kg

Min. Order:1 Piece

The CRBC 15030 UU Crossed roller bearings are suitable for high-precision, high-rigidity, and space-constrained rotary applications. Classic applications include industrial robot joints and positioners, CNC machine tool rotary tables and indexing heads, medical CT scanner rotating frames, radar antenna rotation mechanisms, precision measuring instruments, and aerospace simulation rotary tables.

The CRBC 15030 UU bearing is a Sealed Standard Crossed Roller Bearings With cage with an inner diameter of 150 mm , an outer diameter of 230 mm, a width of 30 mm. It typically uses ABEC-1; ABEC-3; ABEC-5; ABEC-7; ABEC-9 grade precision tolerances and 50Mn,42CrMo rings, GCr15 rolling mlement. It primarily bears radial, thrust and moment, Its dynamic radial rated load is approximately 69200 N, its static radial rated load is approximately 108000 N. It uses T1; C1; C2 standard radial clearance, UU = Two sides sealed; U = One side sealed type, Special synthetic rubber. together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

150 mm

Outside Diameter:

230 mm

Thickness:

30 mm

Weight:

5.3 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

69200

Static load Capacity, Radial (Cor):

108000

Reference speed (Grease rpm):

316

Specifications:

Structure:

Crossed Roller Bearings

Number of Rows:

One

Radial Clearance Trade No.:

T1; C1; C2

Precision Rating:

ABEC-1; ABEC-3; ABEC-5; ABEC-7; ABEC-9

Load Direction:

radial, thrust and moment

Bearing Material:

50Mn,42CrMo

Seals Type:

UU = Two sides sealed; U = One side sealed

Seal Material:

Special synthetic rubber

Rolling Mlement Material:

GCr15

Bore Type:

Cylindrical

Operating Temperature:

-20 to 120 °C

System of Measurement:

Metric

Series:

CRBC..UU

Rolling Element:

cylindrical rollers

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

30 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

CRBC 15030 UU bearings ( 150 mm x 230 mm x 30 mm) have the advantages of The rollers are arranged in a cross pattern, allowing them to withstand radial, axial, and overturning moments simultaneously. They offer high rigidity and rotational accuracy while compact and space-saving design, and easy installation, and are therefore widely used in the Industrial robots, CNC machine tools, medical equipment, precision measuring instruments and aerospace.

Part Number	CRBC 15030 UU
Bearing Type	Sealed Standard Crossed Roller Bearings With cage
Mounting holes	No
Type	CRBC..UU
Seal Type	UU = Two sides sealed; U = One side sealed
Seal Material	Special synthetic rubber
Bore Type	Cylindrical
Rolling Element Type	cylindrical rollers
Oil holes	No
Manufacturer Part Code	CRBC15030UU
Load	radial, thrust and moment
Interchangeable	IKO CRBC 15030 UU
Units	Metric
Rows NO.	One
Rolling Element Material	GCr15
Inner/Outer Ring Material	50Mn,42CrMo
Lubrication	grease
Accuracy class	ABEC-1; ABEC-3; ABEC-5; ABEC-7; ABEC-9
Guidance of cylindrical roller	With cage
Temperature - T(min) [°C]	-20
Temperature - T(max) [°C]	120
Shaft diameter [inch]	5.905
d φ Inside [inch]	5.905
D Φ Outside [inch]	9.055
B Width [inch]	1.181
r min Chamfer [inch]	0.059
da Mounting dimensions [inch]	6.535
Da Mounting dimensions [inch]	7.953
n_B Reference speed (grease) [r/min]	316
C_r Radial Dynamic [lbf]	15556
C_0r Radial Static [lbf]	24278
Internal Clearance	T1; C1; C2
Radial internal clearances - T1	min: -15 µm , max: 0 µm
Radial internal clearances - C1	min: 0 µm , max: 20 µm
Radial internal clearances - C2	min: 20 µm , max: 50 µm
m Bearing Weight [kg]	5.3
Similar Model	CRBC 15030 UU T1 , CRBC 15030 UU T1 P6 CRBC 15030 UU T1 P5 , CRBC 15030 UU T1 P4 CRBC 15030 UU T1 P2 , CRBC 15030 UU C1 CRBC 15030 UU C1 P6 , CRBC 15030 UU C1 P5 CRBC 15030 UU C1 P4 , CRBC 15030 UU C1 P2 CRBC 15030 UU C2 , CRBC 15030 UU C2 P6 CRBC 15030 UU C2 P5 , CRBC 15030 UU C2 P4 CRBC 15030 UU C2 P2 , CRBC 15030 U T1 CRBC 15030 U T1 P6 , CRBC 15030 U T1 P5 CRBC 15030 U T1 P4 , CRBC 15030 U T1 P2 CRBC 15030 U C1 , CRBC 15030 U C1 P6 CRBC 15030 U C1 P5 , CRBC 15030 U C1 P4 CRBC 15030 U C1 P2 , CRBC 15030 U C2 CRBC 15030 U C2 P6 , CRBC 15030 U C2 P5 CRBC 15030 U C2 P4 , CRBC 15030 U C2 P2

The CRBC 15030 UU Crossed roller bearings consist of inner and outer rings, cylindrical rollers, spacers, and seals. The rollers are arranged at 90° intervals within a V-shaped raceway, allowing for multi-directional load bearing even in a single row.

Crossed roller bearings can simultaneously withstand radial loads, bidirectional axial loads, and overturning moments. They possess extremely high rigidity and rotational accuracy, and their compact structure saves installation space, simplifying machine tool design.
