CRBC 03010 NN C1 PD4 Bore 30 Mm, High Rigidity Type (CRBC) Crossed Roller Bearings, Open Type

🔍

CRBC 03010 NN C1 PD4

Bore Diameter:30 mm

Outside Diameter:55 mm

Width:10 mm

Min. Order:1 Piece

The CRBC 03010 NN C1 PD4 Crossed roller bearings are suitable for high-precision, high-rigidity, and space-constrained rotary applications. Classic applications include industrial robot joints and positioners, CNC machine tool rotary tables and indexing heads, medical CT scanner rotating frames, radar antenna rotation mechanisms, precision measuring instruments, and aerospace simulation rotary tables.

The CRBC 03010 NN C1 PD4 bearing is a High rigidity type (CRBC) crossed roller bearings, open type with an inner diameter of 30 mm , an outer diameter of 55 mm, a width of 10 mm. It typically uses PD4 grade precision tolerances and 50Mn,42CrMo rings, GCr15 rolling mlement. It primarily bears radial, thrust and moment, Its dynamic radial rated load is approximately 8200 N, its static radial rated load is approximately 9200 N. It uses C1: Positive clearance standard radial clearance, NN: Open type type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

30 mm

Outside Diameter:

55 mm

Thickness:

10 mm

Performance Data:

Dynamic load Capacity, Radial (Cr):

8200 N

Static load Capacity, Radial (Cor):

9200 N

Specifications:

Structure:

Crossed Roller Bearings

Number of Rows:

One

Radial Clearance Trade No.:

C1: Positive clearance

Precision Rating:

PD4

Load Direction:

radial, thrust and moment

Bearing Material:

50Mn,42CrMo

Seals Type:

NN: Open type

Rolling Mlement Material:

GCr15

Bore Type:

Cylindrical

Operating Temperature:

-30 to 120 °C

System of Measurement:

Metric

Rolling Element:

Cylindrical Rollers

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

30 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

CRBC 03010 NN C1 PD4 bearings ( 30 mm x 55 mm x 10 mm) have the advantages of The rollers are arranged in a cross pattern, allowing them to withstand radial, axial, and overturning moments simultaneously. They offer high rigidity and rotational accuracy while compact and space-saving design, and easy installation, and are therefore widely used in the Industrial robots, CNC machine tools, medical equipment, precision measuring instruments and aerospace.

Part Number	CRBC 03010 NN C1 PD4
Bearing Type	High rigidity type (CRBC) crossed roller bearings, open type
Mounting Holes	Without mounting holes
Design	High rigidity (an inner ring and an outer ring), both inner and outer ring rotation
Rolling Element Type	Cylindrical Rollers
Rows NO.	One
Manufacturer Part Code	CRBC03010NNC1PD4
Load	radial, thrust and moment
Seal symbol	NN: Open type
Accuracy class	PD4
Temperature - T(min) [°C]	-30
Temperature - T(max) [°C]	120
Interchangeable	HIWIN CRBC 03010 NN C1 PD4
Inner/Outer Ring Material	50Mn,42CrMo
Rolling Element Material	GCr15
Axial internal clearance	C1: Positive clearance
d φ Inside [mm]	30
D Φ Outside [mm]	55
T,B Width [mm]	10
d_OH Oil Holes [mm]	1.5
C_r Radial Dynamic [N]	8200
C_0r Radial Static [N]	9200
Mounting dimensions - da [mm]	35
Mounting dimensions - Da [mm]	46.8
Mounting dimensions - Du [mm]	47.5
Ca max Fillet Radius [mm]	0.6

The CRBC 03010 NN C1 PD4 Crossed roller bearings consist of inner and outer rings, cylindrical rollers, spacers, and seals. The rollers are arranged at 90° intervals within a V-shaped raceway, allowing for multi-directional load bearing even in a single row.

Crossed roller bearings can simultaneously withstand radial loads, bidirectional axial loads, and overturning moments. They possess extremely high rigidity and rotational accuracy, and their compact structure saves installation space, simplifying machine tool design.
