CRBB03510 Bore 35 Mm, Split Inner Ring Type (CRBB) Crossed Roller Bearings, Sealed And Open Type
The CRBB03510 Crossed roller bearings are suitable for high-precision, high-rigidity, and space-constrained rotary applications. Classic applications include industrial robot joints and positioners, CNC machine tool rotary tables and indexing heads, medical CT scanner rotating frames, radar antenna rotation mechanisms, precision measuring instruments, and aerospace simulation rotary tables.
The CRBB03510 bearing is a Split inner ring type (CRBB) crossed roller bearings, sealed and open type with an inner diameter of 35 mm , an outer diameter of 60 mm, a width of 10 mm. It typically uses P5, P4, P2, PD5 grade precision tolerances and 50Mn,42CrMo rings, GCr15 rolling mlement. It primarily bears radial, thrust and moment, Its dynamic radial rated load is approximately 8500 N, its static radial rated load is approximately 10000 N. It uses C1: Positive clearance; C8: Negative clearance standard radial clearance, WW: Double sides Sealed type; NN: Open type type, NBR (Nitrile Butadiene Rubber). together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.
CRBB03510 bearings ( 35 mm x 60 mm x 10 mm) have the advantages of The rollers are arranged in a cross pattern, allowing them to withstand radial, axial, and overturning moments simultaneously. They offer high rigidity and rotational accuracy while compact and space-saving design, and easy installation, and are therefore widely used in the Industrial robots, CNC machine tools, medical equipment, precision measuring instruments and aerospace.
| Part Number | CRBB03510 |
| Bearing Type | Split inner ring type (CRBB) crossed roller bearings, sealed and open type |
| Mounting Holes | Without mounting holes |
| Design | Split inner ring (two inner semi-rings and an outer ring), outer ring rotation |
| Rolling Element Type | Cylindrical Rollers |
| Rows NO. | One |
| Manufacturer Part Code | CRBB 03510 |
| Load | radial, thrust and moment |
| Seal symbol | WW: Double sides Sealed type; NN: Open type |
| Seal Material | NBR (Nitrile Butadiene Rubber) |
| Accuracy class | P5, P4, P2, PD5 |
| Temperature - T(min) [°C] | -30 |
| Temperature - T(max) [°C] | 120 |
| Interchangeable | HIWIN CRBB03510 |
| Inner/Outer Ring Material | 50Mn,42CrMo |
| Rolling Element Material | GCr15 |
| Axial internal clearance | C1: Positive clearance; C8: Negative clearance |
| C8 [µm] | -8 (min), 0 (max) |
| C1 [µm] | 2 (min), 15 (max) |
| d φ Inside [mm] | 35 |
| D Φ Outside [mm] | 60 |
| T,B Width [mm] | 10 |
| dOH Oil Holes [mm] | 1.5 |
| Cr Radial Dynamic [N] | 8500 |
| C0r Radial Static [N] | 10000 |
| Mounting dimensions - da [mm] | 40 |
| Mounting dimensions - du [mm] | 39.4 |
| Mounting dimensions - Da [mm] | 51.8 |
| Ca max Fillet Radius [mm] | 0.6 |
| Similar Model | CRBB03510 WW C1 P5 CRBB03510 NN C1 P5 CRBB03510 WW C8 P5 CRBB03510 NN C8 P5 CRBB03510 WW C1 P4 CRBB03510 NN C1 P4 CRBB03510 WW C8 P4 CRBB03510 NN C8 P4 CRBB03510 WW C1 P2 CRBB03510 NN C1 P2 CRBB03510 WW C8 P2 CRBB03510 NN C8 P2 CRBB03510 WW C1 PD5 CRBB03510 NN C1 PD5 CRBB03510 WW C8 PD5 CRBB03510 NN C8 PD5 |
The CRBB03510 Crossed roller bearings consist of inner and outer rings, cylindrical rollers, spacers, and seals. The rollers are arranged at 90° intervals within a V-shaped raceway, allowing for multi-directional load bearing even in a single row.
Crossed roller bearings can simultaneously withstand radial loads, bidirectional axial loads, and overturning moments. They possess extremely high rigidity and rotational accuracy, and their compact structure saves installation space, simplifying machine tool design.
