CRBB 08016 NN C1 P4 Bore 80 Mm, Split Outer Ring Type (CRBA) Crossed Roller Bearings, Open Type

🔍

CRBB 08016 NN C1 P4

Bore Diameter:80 mm

Outside Diameter:120 mm

Width:16 mm

Weight:0.7 kg

Min. Order:1 Piece

The CRBB 08016 NN C1 P4 Crossed roller bearings are suitable for high-precision, high-rigidity, and space-constrained rotary applications. Classic applications include industrial robot joints and positioners, CNC machine tool rotary tables and indexing heads, medical CT scanner rotating frames, radar antenna rotation mechanisms, precision measuring instruments, and aerospace simulation rotary tables.

The CRBB 08016 NN C1 P4 bearing is a Split outer ring type (CRBA) crossed roller bearings, open type with an inner diameter of 80 mm , an outer diameter of 120 mm, a width of 16 mm. It typically uses P4 = (ISO Class 4 / ABEC-7) grade precision tolerances and 50Mn,42CrMo rings, GCr15 rolling mlement. It primarily bears radial, thrust and moment, Its dynamic radial rated load is approximately 30200 N, its static radial rated load is approximately 44800 N. Its dynamic axial rated load is approximately 102000 N, its static axial rated load is approximately 67000 N. It uses C1: Positive clearance standard radial clearance, NN: Open type type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

80 mm

Outside Diameter:

120 mm

Thickness:

16 mm

Weight:

0.7 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

30200 N

Static load Capacity, Radial (Cor):

44800 N

Dynamic load Capacity, axial:

102000 N

Static load Capacity, axial:

67000 N

Reference speed (Grease rpm):

600

Limiting speed (Oil rpm):

800

Specifications:

Structure:

Crossed Roller Bearings

Number of Rows:

One

Radial Clearance Trade No.:

C1: Positive clearance

Precision Rating:

P4 = (ISO Class 4 / ABEC-7)

Load Direction:

radial, thrust and moment

Bearing Material:

50Mn,42CrMo

Seals Type:

NN: Open type

Rolling Mlement Material:

GCr15

Bore Type:

Cylindrical

Operating Temperature:

-30 to 120 °C

System of Measurement:

Metric

Rolling Element:

Cylindrical Rollers

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

30 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

CRBB 08016 NN C1 P4 bearings ( 80 mm x 120 mm x 16 mm) have the advantages of The rollers are arranged in a cross pattern, allowing them to withstand radial, axial, and overturning moments simultaneously. They offer high rigidity and rotational accuracy while compact and space-saving design, and easy installation, and are therefore widely used in the Industrial robots, CNC machine tools, medical equipment, precision measuring instruments and aerospace.

Part Number	CRBB 08016 NN C1 P4
Bearing Type	Split outer ring type (CRBA) crossed roller bearings, open type
Mounting Holes	Without mounting holes
Design	Split inner ring (two inner semi-rings and an outer ring), outer ring rotation
Rolling Element Type	Cylindrical Rollers
Rows NO.	One
Manufacturer Part Code	CRBB08016NNC1P4
Load	radial, thrust and moment
Seal symbol	NN: Open type
Accuracy class	P4 = (ISO Class 4 / ABEC-7)
Temperature - T(min) [°C]	-30
Temperature - T(max) [°C]	120
Interchangeable	HIWIN CRBB 08016 NN C1 P4
Inner/Outer Ring Material	50Mn,42CrMo
Rolling Element Material	GCr15
Axial internal clearance	C1: Positive clearance
C1 [µm]	2 (min), 20 (max)
d φ Inside [mm]	80
D Φ Outside [mm]	120
T,B Width [mm]	16
d_OH Oil Holes [mm]	2.5
C_r Radial Dynamic [N]	30200
C_0r Radial Static [N]	44800
C_a Dynamic Axial [N]	102000
C_0a Static Axial [N]	67000
m Weight [kg]	0.7
n_B Reference speed (grease) [r/min]	600
n_G Limiting speed (oil) [r/min]	800
Mounting dimensions - da [mm]	92
Mounting dimensions - du [mm]	89
Mounting dimensions - Da [mm]	109
Ca max Fillet Radius [mm]	0.6
Td max Idling torque [Nm]	0.63

The CRBB 08016 NN C1 P4 Crossed roller bearings consist of inner and outer rings, cylindrical rollers, spacers, and seals. The rollers are arranged at 90° intervals within a V-shaped raceway, allowing for multi-directional load bearing even in a single row.

Crossed roller bearings can simultaneously withstand radial loads, bidirectional axial loads, and overturning moments. They possess extremely high rigidity and rotational accuracy, and their compact structure saves installation space, simplifying machine tool design.
