CRB25030C1 Standard Crossed Roller Bearings Full Complement
The CRB25030C1 Crossed roller bearings are suitable for high-precision, high-rigidity, and space-constrained rotary applications. Classic applications include industrial robot joints and positioners, CNC machine tool rotary tables and indexing heads, medical CT scanner rotating frames, radar antenna rotation mechanisms, precision measuring instruments, and aerospace simulation rotary tables.
The CRB25030C1 bearing is a Standard Crossed Roller Bearings Full Complement with an inner diameter of 250 mm , an outer diameter of 330 mm, a width of 30 mm. It typically uses P0 (ISO Class NORMAL / ABEC-1) grade precision tolerances and 50Mn,42CrMo rings, GCr15 rolling mlement. It primarily bears radial, thrust and moment, Its dynamic radial rated load is approximately 146000 N, its static radial rated load is approximately 283000 N. It uses C1 standard radial clearance, Open type type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.
CRB25030C1 bearings ( 250 mm x 330 mm x 30 mm) have the advantages of The rollers are arranged in a cross pattern, allowing them to withstand radial, axial, and overturning moments simultaneously. They offer high rigidity and rotational accuracy while compact and space-saving design, and easy installation, and are therefore widely used in the Industrial robots, CNC machine tools, medical equipment, precision measuring instruments and aerospace.
| Part Number | CRB25030C1 |
| Bearing Type | Standard Crossed Roller Bearings Full Complement |
| Mounting holes | No |
| Type | CRB |
| Seal Type | Open type |
| Bore Type | Cylindrical |
| Rolling Element Type | cylindrical rollers |
| Oil holes | No |
| Manufacturer Part Code | CRB 25030 C1 |
| Load | radial, thrust and moment |
| Interchangeable | IKO CRB25030C1 |
| Units | Metric |
| Rows NO. | One |
| Rolling Element Material | GCr15 |
| Inner/Outer Ring Material | 50Mn,42CrMo |
| Lubrication | grease |
| Accuracy class | P0 (ISO Class NORMAL / ABEC-1) |
| Guidance of cylindrical roller | Full complement |
| Temperature - T(min) [°C] | -20 |
| Temperature - T(max) [°C] | 120 |
| Shaft diameter [inch] | 9.843 |
| d φ Inside [inch] | 9.843 |
| D Φ Outside [inch] | 12.992 |
| B Width [inch] | 1.181 |
| r min Chamfer [inch] | 0.098 |
| da Mounting dimensions [inch] | 10.433 |
| Da Mounting dimensions [inch] | 12.205 |
| nB Reference speed (grease) [r/min] | 172 |
| nG Limiting speed (oil) [r/min] | 259 |
| Cr Radial Dynamic [lbf] | 32820 |
| C0r Radial Static [lbf] | 63618 |
| Internal Clearance | C1 |
| Radial internal clearances - C1 | min: 0 µm , max: 25 µm |
| m Bearing Weight [kg] | 8.1 |
| Similar Model | CRB 25030 C1 P6 CRB 25030 C1 P5 CRB 25030 C1 P4 CRB 25030 C1 P2 |
The CRB25030C1 Crossed roller bearings consist of inner and outer rings, cylindrical rollers, spacers, and seals. The rollers are arranged at 90° intervals within a V-shaped raceway, allowing for multi-directional load bearing even in a single row.
Crossed roller bearings can simultaneously withstand radial loads, bidirectional axial loads, and overturning moments. They possess extremely high rigidity and rotational accuracy, and their compact structure saves installation space, simplifying machine tool design.
