CF10VUUR Stud Type Track Roller (Alt P/N: MCF-22A-S)

🔍

CF10VUUR

Bore Diameter:10 mm

Outside Diameter:22 mm

Width:36.2 mm

Min. Order:1 Piece

The CF10VUUR bearing is a Track Rollers with an inner diameter of 10 mm , an outer diameter of 22 mm, a width of 36.2 mm. It typically uses Standard grade precision tolerances and Chrome Steel (Gcr15) rings. Its dynamic radial rated load is approximately 9570 (N), its static radial rated load is approximately 14500 (N). Sealed type, Rubber. together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Equivalent: MCF-22A-S

Application: Conveyors, Process Transfer Lines, Power Generation, Metal Processing, Transportation, Food Processing, and Packaging.

Dimensions:

Inside Diameter:

10 mm

Outside Diameter:

22 mm

Thickness:

36.2 mm

Performance Data:

Dynamic load Capacity, Radial (Cr):

9570 (N)

Static load Capacity, Radial (Cor):

14500 (N)

Specifications:

HS Code:

8482400090

Structure:

Roller Bearing

Number of Rows:

Single

Demensions:

10x22x36.2

Brand:

Neutral Product

Precision Rating:

Standard

Bearing Material:

Chrome Steel (Gcr15)

Seals Type:

Sealed

Seal Material:

Rubber

Roller Material:

Chrome Steel (Gcr15)

Operating Temperature Range:

-40℃ to 120℃

Series:

CF..VUUR

Rolling Element:

Roller

Closure Type:

Sealed

Transaction Information:

Transport Package:

Standard Export Package

Shipping Ways:

by Sea or Air

Country of Origin:

China

Stock:

1000 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

CF10VUUR Cam Follower (Interchange Part No.: MCF-22A-S), Crowned Outer Ring, Without Cage, Sealed Type, High Radial Load Carrying Capacity, Long Service Life, Easy to Mount.

Size: 10x22x36.2mm

Stud Diameter (d1): 10 mm

Outer Diameter (D): 22 mm

Outer Ring Width (C): 12 mm

Overall Length (B1): 36.2 mm

Rolling Elements: Rollers

Number of Rows: 1

Feature for Tightening: With Head Hexagonal Hole

Roller Guide Method: Without Cage (Full Complement Needle Roller Set)

V: Full Complement Type

UU: Sealed Type

R: Crowned Outer Ring

Material: Bearing Steel

Shape of Outer Ring Outside Surface: Crowned Outer Ring

Operating Temperature Range: -40 to 120 ºC

HS Code: 8482400090

Part No.	Weight	Dimension						Basic Dynamic Load Rating	Basic Static Load Rating	Interchange Part No.
	Weight	d1	D	G	C	MAX. B	MAX. B1	Basic Dynamic Load Rating	Basic Static Load Rating	MCGILL
	g	mm						(N)	(N)	MCF..S
CF10VUUR	46	10	22	M10X1.25	12	13.2	36.2	9570	14500	MCF-22A-S

Cam followers (stud-type track rollers) are designed to run on all types of tracks and to be used in cam drives, conveyor systems, etc. They are based on a needle roller bearing with a threaded solid stud instead of an inner ring. They have a thick-walled outer ring with a cylindrical running surface and are supplied ready-to-mount. A narrow gap between the outer ring and the adjacent components forms a gap-type seal. The bearings can be relubricated via the stud.

Cam followers are widely employed in industrial applications involving conveyors, process transfer lines, power generation, metal processing, transportation, food processing, and packaging.

All the bearings we are offering are direct factory price, fast delivery, perfect quality. For more bearings, please feel free to mail us at [email protected] or contact us by Wechat or Whatsapp at +8618062246726.
