CB-10ET Rod End (Shaft Dia: 0.625 Inch)
The CB-10ET bearing is a Rod Ends with an inner diameter of 0.625 inch , together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.
Application: Steering and shifting mechanisms, general purpose linkages, packaging equipment, and light-duty mechanical assemblies.
CB-10ET rod end, male threaded, left hand, corrosion resistant. Long service life, and smooth articulation.
Bore Diameter: 0.625 Inch (15.875 mm)
Thread Size: 5/8-18 UNF-3A
Thread Direction: Left Hand
Rod End Type: Male
HS Code: 8482109000
|
Rod End |
||
|
Part Number |
CB-10ET |
|
|
Thread Type |
Left Hand |
|
|
Thread Configuration |
Male |
|
|
Size |
Inch |
mm |
|
B - Ball Bore |
0.625 |
15.875 |
|
W - Ball Width |
0.75 |
19.05 |
|
H - Head Width |
0.484 |
12.29 |
|
A - Base to Center |
2.625 |
66.68 |
|
D - Head Diameter |
1.5 |
38.1 |
|
Ball Diameter |
1.062 |
26.97 |
|
C - Thread Length |
1.625 |
41.28 |
|
Thread UNF-3A |
5/8-18 |
|
|
a° Misalignment Angle |
22 |
|
|
Ultimate Radial Static Load Capacity (Lbs) |
16,922 |
|
|
Approximate Brg. Weight (Grams) |
163 |
|
Body - 17-4 PH stainless steel - heat treated.
Ball - 440C stainless steel - heat treated - hard chrome plated (MFG. option).
Bushing – 17-4 PH stainless steel - heat treated - PTFE lined.
Studded configuration available upon request. Specify by adding suffix "S". Ex.: CM-8ETS.
Applications:
Automotive: Steering and shifting mechanisms
Industrial & Automation: General purpose linkages, packaging equipment, and light-duty mechanical assemblies.
