C 2211 KV + H 311 E Bore 50 Mm, CARB Toroidal Roller Bearings Full Complement On An Adapter Sleeve

🔍

C 2211 KV + H 311 E

Bore Diameter:50 mm

Outside Diameter:100 mm

Width:25 mm

Weight:1.15 kg

Min. Order:1 Piece

The C 2211 KV + H 311 E CARB ring roller bearings are widely used in continuously operating equipment where misalignment and thermal expansion occur, specifically including: papermaking machinery (drying cylinders, calenders), wind power generation (main shafts), industrial gearboxes, continuous casting lines, ship propulsion shafts, and large wind turbines.

The C 2211 KV + H 311 E bearing is a CARB toroidal roller bearings Full complement on an adapter sleeve with an inner diameter of 50 mm , an outer diameter of 100 mm, a width of 25 mm. It typically uses PN grade precision tolerances and GCr15SiMn rings, GCr15SiMn rolling mlement. It uses CN standard radial clearance, Open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

50 mm

Outside Diameter:

100 mm

Thickness:

25 mm

Weight:

1.15 KG

Specifications:

Structure:

Toroidal roller bearings

Number of Rows:

One

Radial Clearance Trade No.:

Precision Rating:

Bearing Material:

GCr15SiMn

Cage Type:

V = Full complement of rollers (no cage)

Seals Type:

Open

Rolling Mlement Material:

GCr15SiMn

Bore Type:

K = Tapered bore (taper = 1:12)

Operating Temperature:

-40 to 150 °C

System of Measurement:

Metric

Series:

C 22 series (C 22.. KV + H)

Rolling Element:

cylindrical rollers

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

100 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

C 2211 KV + H 311 E bearings ( 50 mm x 100 mm x 25 mm) have the advantages of Self-aligning + displacement, high load capacity, long service life, and are therefore widely used in the Papermaking machinery, wind turbines, industrial gearboxes, material conveying equipment and vibrating screens.

Part Number	C 2211 KV + H 311 E
Interchangeable	SKF C 2211 KV + H 311 E
Cage	V = Full complement of rollers (no cage)
Bearing Type	CARB toroidal roller bearings Full complement on an adapter sleeve
Load	radial
Accuracy class	PN
Bearing part	Complete
Internal clearance	CN
Row NO.	One
Heat stabilized	200 °C (390 °F)
Seal	Open
Units	Metric
Manufacturer Part Code	C2211KV + H311E
Series	C 22 series (C 22.. KV + H)
Lubrication	NO
Locating feature	NO
Relubrication feature	NO
Adapter sleeve	H 311 E
Weight [lb]	2.5353
d φ Inside [inch]	1.9685
D Φ Outside [inch]	3.9370
B Thickness [inch]	0.9843
d₁ [inch]	1.9685
B_a min [inch]	0.3937
d_b min [inch]	2.3622
d_a max [inch]	3.150

The C 2211 KV + H 311 E CARB ring roller bearings consist of an inner ring (with double raceways), a spherical outer ring, ring rollers (symmetrical rollers with a special profile), and a cage. The outer ring raceways are spherical, and the rollers are arranged in a ring, combining the structural characteristics of self-aligning roller bearings and cylindrical roller bearings.

CARB ring roller bearings integrate self-aligning capability and axial displacement capability, compensating for shaft bending and misalignment (self-aligning function) while allowing bidirectional axial displacement between the shaft and the bearing housing (floating function). They have extremely high radial load capacity, with line contact between the rollers and raceways, resulting in uniform stress distribution. Their compact structure allows them to replace the combination of self-aligning roller bearings and floating end bearings, simplifying system design.
