Brass Cage 180TAC03DMSUELPN5D Angular Contact Super Precision Bearings For Ball Screw Support

🔍

180TAC03DMSUELPN5D

Bore Diameter:180 mm

Outside Diameter:380 mm

Width:75 mm

Weight:43.8 kg

Min. Order:1 Piece

The 180TAC03DMSUELPN5D Ball screw support bearings are widely used in the feed drive systems of CNC machine tools, specifically including: machining centers (X/Y/Z axis screw support), CNC lathes (Z-axis), EDM machines, precision grinding machines, industrial robots (linear modules), and semiconductor equipment (wafer positioning platforms).

The 180TAC03DMSUELPN5D bearing is a Angular Contact Super Precision Thrust Ball Bearings, TAC 03 Series for Ball Screw Support (High-Load Drive) with an inner diameter of 180 mm , an outer diameter of 380 mm, a width of 75 mm. It typically uses PN5D = Standard accuracy (ISO Class 5) grade precision tolerances and GCr15SiMn rings, GCr15SiMn rolling mlement. Open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

180 mm

Outside Diameter:

380 mm

Thickness:

75 mm

Weight:

43.8 KG

Reference speed (Grease rpm):

953

Limiting speed (Oil rpm):

1369

Specifications:

Structure:

Ball Screw Support Bearings

Number of Rows:

One

Precision Rating:

PN5D = Standard accuracy (ISO Class 5)

Bearing Material:

GCr15SiMn

Cage Type:

M = Brass Cage

Seals Type:

Open

Rolling Mlement Material:

GCr15SiMn

Bore Type:

Cylindrical

System of Measurement:

Metric

Series:

TAC 03 Series (..TAC03DMSUELPN5D)

Rolling Element:

balls

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

180TAC03DMSUELPN5D bearings ( 180 mm x 380 mm x 75 mm) have the advantages of High axial stiffness and load-bearing capacity, 60° contact angle design, pre-installed and pre-loaded for easy installation, optional sealing for maintenance-free operation, and are therefore widely used in the Machine tool ball screws, machining centers, automated equipment, robots, precision measuring devices.

Part Number	180TAC03DMSUELPN5D
Bearing Type	Angular Contact Super Precision Thrust Ball Bearings, TAC 03 Series for Ball Screw Support (High-Load Drive)
Internal design	D = Contact angle 55 °
Contact angle - α	55 °
Type	TAC
Dimension series	03 = 03 Series
Preload	EL = Extra light preload
Arrangement row	One
Arrangement	SU = Universal (One-row)
SU Bearing Mass - m [lb]	96.5615
DB/DF Arrangement H preload [lbf]	431
DB/DF Arrangement H Axial Rigidity	1281 N/µm
DB/DF Arrangement H Starting Torque	0.30 N･m
DB/DF Arrangement H Measured Axial Clearance	-12 µm
Speed ratings (grease) - n_B	953 min^–1
Speed ratings (oil) - n_G	1369 min^–1
Recommended Grease Quantities - CC	624 g/brg
Dimension
d φ Inside [inch]	7.0866
D Φ Outside [inch]	14.9606
B Width [inch]	2.9527
r min Chamfer [inch]	0.1575
r₁ min Chamfer [inch]	0.0591
d₁ Shoulder [inch]	8.9370
d₂ Shoulder [inch]	10.8504
D₁ Shoulder/Recess [inch]	11.2165
D₂ Shoulder/Recess [inch]	13.3386
Dynamic Axial Capacity
C_a 1 row [lbf]	183141
C_a 2 row [lbf]	298875
C_a 3 row [lbf]	395592
C_a 4 row [lbf]	483211
C_a 5 row [lbf]	566407
Static Axial Capacity
C_0a 1 row [lbf]	305698
C_0a 2 row [lbf]	611364
C_0a 3 row [lbf]	921633
C_0a 4 row [lbf]	1225088
C_0a 5 row [lbf]	1528595
Other Arrangement	1 rows: DB(<>): 180TAC03DMDBELPN5D DF(><): 180TAC03DMDFELPN5D 2 rows: DT(<<): 180TAC03DMDTELPN5D DFD(><<): 180TAC03DMDFDELPN5D DFF(>><<): 180TAC03DMDFFELPN5D DBD(<<>): 180TAC03DMDBDELPN5D DBB(<<>>): 180TAC03DMDBBELPN5D 3 rows: DFT(><<<): 180TAC03DMDFTELPN5D DFFD(>><<): 180TAC03DMDFFDELPN5D DFFF(>>><<<): 180TAC03DMDFFFELPN5D DBT(<<<>): 180TAC03DMDBTELPN5D DBBD(<<<>>): 180TAC03DMDBBDELPN5D DBBB(<<<>>>): 180TAC03DMDBBBELPN5D 4 rows: DFTD(><<<<): 180TAC03DMDFTDELPN5D DFFT(>><<<<): 180TAC03DMDFFTELPN5D DBTD(<<<<>): 180TAC03DMDBTDELPN5D DBBT(<<<<>>): 180TAC03DMDBBTELPN5D 5 rows: DFTT(><<<<<): 180TAC03DMDFTTELPN5D DBTT(<<<<<>)180TAC03DMDBTTELPN5D

The 180TAC03DMSUELPN5D Ball screw support bearings are typically composed of high-precision angular contact ball bearings paired back-to-back (DB) or in series (DT) configurations. They feature a small contact angle (15° or 20°) and high-rigidity cages (phenolic resin or brass) on both inner and outer rings, achieving a precision grade of P4 or higher. Some models integrate seals and lubrication holes, forming a preload unit.

Ball screw support bearings offer extremely high axial rigidity and load-bearing capacity, accurately withstanding bidirectional axial loads in screw drives. The back-to-back configuration provides anti-overturning moment capability, ensuring positioning accuracy. The preload design eliminates axial backlash, achieving backlash-free, low-friction operation with low heat generation, making them suitable for high-speed feed. They are factory-installed and ready to use, simplifying installation and adjustment.
