BMO-6206/064S2/UA008A Motor Encoder Sensor Bearing 30x62x22mm
The BMO-6206/064S2/UA008A bearing is a sensor bearing with an inner diameter of 30 mm , an outer diameter of 62 mm, a width of 22 mm. RZ/RS type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.
Feature: Low friction and long life
Application: Forklift Motors/Trucks / Tractors / Harvesters
BMB-6206/064S2/UA008A Motor Encoder Sensor Bearing 30x62x22mm
Motor encoder unit, with enhanced sensor protection, combine bearing and sensor functionality into a single, compact, robust and easy to install unit. They enable accurate and continuous monitoring of speed and direction of rotation. The units include integrated protection for their electronic sensors that enables them to deliver accurate data, even in harsh electromagnetic environments, while avoiding electronic failures, which can result in a reduction of maintenance and warranty costs.
|
Product Name |
BMB-6206/064S2/UA008A |
Package |
Carton Box+Pallet |
|
Size: |
30x62x22mm |
Material |
Bearing Steel |
|
Number of Row |
Single Row |
Bore type |
Cylindrical |
|
Precision Grade |
P6 P5 |
Lubrication |
Grease |
|
HS Code |
8482102000 |
Certifications |
ISO9001:2015 |
|
Inside Diameter (d): |
30mm |
Cage |
Non-metallic |
|
Outside Diameter (D): |
62mm |
Place of Origin: |
France |
|
Thickness (T): |
22mm |
Bearing Type |
Motor Encoder Unit |
|
Brand Name |
OEM Service |
Payment Term |
TT/Western Union/Paypal |
|
Seals Type |
Seal on one side |
Weight |
0.4kg |
|
Structure: |
Deep Groove Ball Bearing |
Application |
Forklift Trucks / Tractors / Harvesters / Motors |
|
Limiting Speed |
7500 r/min |
Snap Ring |
SP 62 |
|
Cable Connector Type |
With Connector/Free Cable End |
Number of Pulses |
64 Pulses Per Revolution |
Please contact Cherry if you are interested in this product:
WhatsApp: 0086 13825082601
Mobile: 0086 18928876761
Email: [email protected]
