BC4-0106 Four-row Cylindrical Roller Bearing 200290192mm

🔍

BC4-0106

Bore Diameter:200 mm

Outside Diameter:290 mm

Width:192 mm

Weight:43 kg

Min. Order:1 Piece

The BC4-0106 bearing is a Cylindrical Roller Bearings with an inner diameter of 200 mm , an outer diameter of 290 mm, a width of 192 mm. It typically uses standard precision grade precision tolerances and features a Machined metal cage, Its dynamic radial rated load is approximately 1930kN, its static radial rated load is approximately 3200kN. open type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Application: Iron and steel mine metallurgical papermaking cement

Dimensions:

Inside Diameter:

200 mm

Outside Diameter:

290 mm

Thickness:

192 mm

Weight:

43 KG

Performance Data:

Dynamic load Capacity, Radial (Cr):

1930kN

Static load Capacity, Radial (Cor):

3200kN

Reference speed (Grease rpm):

1600 r/min

Limiting speed (Oil rpm):

2400 r/min

Specifications:

Structure:

Cylindrical Roller

Number of Rows:

four

Precision Rating:

standard precision

Bearing Material:

steel

Cage material:

Machined metal

Seals Type:

open

Bore Type:

Cylindrical

Transaction Information:

Transport Package:

carton box

Service:

customized

Shipping Ways:

By express/ By air/Ocean freight

Stock:

800 Piece

Port:

Hong Kong

Payment term:

Paypal/Western Union/TT.etc

Delivery time:

3-5 working days after receiving your payment

Detailed description

Model:	BC4-0106
Main parameters
d-Bore diameter:200mm D-Outside diameter:290mm B-Total bearing width over inner ring(s):192mm C-Total bearing width over outer ring(s):192mm D1-Outer ring shoulder diameter:259.9mm F-Raceway diameter inner ring:226mm r1,2-Corner radius/chamfer inner ring(min.): 2.1mm r3,4-Chamfer dimension on the outer ring(min.):2.1mm M-Mass: 43kg
Other parameters
Basic dynamic load rating:1930kN Basic static load rating:3200kN Fatigue load limit:320kN Reference speed:1600r/min Limiting speed:2400r/min Bearing part:complete bearing Number of rows:four Bore type:Cylindrical Cage:Machined metal Number of flanges, outer ring:5 Number of flanges, inner ring:0 Radial internal clearance:C4
Application Scenario
Iron and steel mine metallurgical papermaking cement
service
If you are interested in this bearing or if you need other types of bearings, please feel free to contact me and we look forward to cooperating with you!

Share this product to:

Let more people see your product

How can you buy BC4-0106 Four-row Cylindrical Roller Bearing 200*290*192mm on the Internet?
High quality BC4-0106 ( 43 kg Mass, ID: 200 mm OD: 290 mm WD: 192 mm , four Rows , standard precision Accuracy Class , steel Material , 1930kN Radial dynamic , 3200kN Radial static ), Just click the button " Contact Now " to mention your purchase Requirement , Quantity and Contact Method of your requested Bearing Item No. BC4-0106. then click the button " Send " The web site will make your purchasing information sent to the supplier's mailbox, who will come to contact you upon they get your information at the first time.
