Axial Cylindrical Roller Bearings 89432-M 160x320x95mm

🔍

89432-M

Bore Diameter:160 mm

Outside Diameter:320 mm

Width:95 mm

Weight:42 kg

The 89432-M bearing is a Axial cylindrical roller bearings with an inner diameter of 160 mm , an outer diameter of 320 mm, a width of 95 mm. It typically uses P4 P5 grade precision tolerances and open or sealed type, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

160 mm

Outside Diameter:

320 mm

Thickness:

95 mm

Weight:

42 KG

Specifications:

Structure:

Axial cylindrical roller bearings

Precision Rating:

P4 P5

Bearing Material:

chrome steel

Seals Type:

open or sealed

Transaction Information:

Payment term:

as your need

Delivery time:

in stock

Detailed description

Axial cylindrical roller bearings 89432-M

single direction, comprising K894, GS, WS

d 160 mm

D 320 mm

T 95 mm

D1 164 mm

d1 320 mm

rmin 5 mm

m 42 kg Mass

Ca 1780000 N Basic dynamic load rating, axial

C0a 6500000 N Basic static load rating, axial

Cua 590000 N Fatigue limit load

nG 1170 1/min Limiting speed

nB 410 1/min Reference speed

K89432-M

Allocated axial cylindrical roller and cage assembly

GS89432

Allocated housing locating washer

WS89432

Allocated shaft locating washer
