SKF NN 3014 TN/SP bearing stock, Dimensions, Drawing

d 70mm double row, high-precision
D 110mm Cylindrical roller bearings,
B 30mm  Principal dimensions
c 96,8kN dynamic Basic load ratings
Co 150kN static static|Basic load ratings
Pu 17,3kN limit Fatigue
grease  7500r/min   Attainable speeds when lubricating with grease
oil-air 8500r/min  Attainable speeds when lubricating with oil-air
Mass 1,00KG
Bearing NN 3014 TN/SP  Designations
Pu: 17,3kN limit Fatigue
Co: 150kN static static|Basic load ratings
oil-air: 8500r/min  Attainable speeds when lubricating with oil-air
Mass: 1,00KG
c: 96,8kN dynamic Basic load ratings
grease : 7500r/min   Attainable speeds when lubricating with grease
Bearing: NN 3014 TN/SP  Designations
