90tVL710 Single-row Angular Contact Thrust Ball Bearing

🔍

90tVL710

Bore Diameter:228.6 mm

Outside Diameter:295.275 mm

Width:38.1 mm

Weight:6.2 kg

Min. Order:1 Piece

The 90tVL710 Thrust angular contact ball bearings are mainly suitable for applications requiring high speed, low friction, and simultaneous axial and certain radial loads, such as fluid control valves, machine tool worktables and spindles, and rotary tables in the oil and gas drilling industry.

The 90tVL710 bearing is a Single-row angular contact thrust ball bearing with an inner diameter of 228.6 mm , an outer diameter of 295.275 mm, a width of 38.1 mm. It typically uses PN (ABEC-1) grade precision tolerances and bearing steel rings, bearing steel rolling mlement. Its dynamic axial rated load is approximately 138834 N, its static axial rated load is approximately 477514 N. together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.

Dimensions:

Inside Diameter:

228.6 mm

Outside Diameter:

295.275 mm

Thickness:

38.1 mm

Weight:

6.2 KG

Dynamic load Capacity, axial:

138834 N

Static load Capacity, axial:

477514 N

Specifications:

Structure:

Thrust Angular Contact Ball Bearings

Number of Rows:

One

Precision Rating:

PN (ABEC-1)

Bearing Material:

bearing steel

Rolling Mlement Material:

bearing steel

Bore Type:

Cylindrical bore

Operating Temperature:

-30 to 110 °C

System of Measurement:

Metric

Series:

TVL

Transaction Information:

Transport Package:

Standard Export Package

Service:

7*24 hour

Shipping Ways:

by Sea or Air

Country of Origin:

china

Stock:

200 Piece

Port:

Tianjin, Shanghai, Shenzhen, Guangzhou or Qingdao

Payment term:

by T/T in advance

Delivery time:

2-3 days for stock, 25-30 days for bulk production

Detailed description

90tVL710 bearings ( 228.6 mm x 295.275 mm x 38.1 mm) have the advantages of Composite load, high speed, high rigidity, and are therefore widely used in the rotary tables of oil and gas drilling rigs.

Part Number	90tVL710
Design type	TVL: Single-row angular contact construction
Bearing Type	Single-row angular contact thrust ball bearing
Interchangeable	TIMKEN 90tVL710
Manufacturer Part Code	90 TVL 710
Series	TVL
Units	Metric
Tolerance class	PN (ABEC-1)
C_0a Axial Static [lbf]	107345
C_a Axial Dynamic [lbf]	31209
d φ Inside [inch]	9.0000
D Φ Outside [inch]	11.6250
T Width [inch]	1.5000
r Fillet Radius [inch]	0.1260
d₁ [inch]	9.6874
D₁ [inch]	10.9374
E (Max) Shoulder Diameter Housing [inch]	10.3110
H (Min) Shoulder Diameter Shaft [inch]	10.3110
Weight [lb]	13.6685

The 90tVL710 Thrust angular contact ball bearings are mainly composed of precision-ground steel balls, hardened and ground steel raceways, and a brass (or bronze) cage. Their core characteristic is their ability to simultaneously withstand axial thrust loads and a certain amount of radial load, and they also feature low friction, quiet operation, and suitability for high-speed operation.

Share this product to:

Let more people see your product

How can you buy 90tVL710 Single-row Angular Contact Thrust Ball Bearing on the Internet?
High quality 90tVL710 ( 6.2 kg Mass, ID: 228.6 mm OD: 295.275 mm WD: 38.1 mm , TVL Series , One Rows , PN (ABEC-1) Accuracy Class , bearing steel Material ), Just click the button " Contact Now " to mention your purchase Requirement , Quantity and Contact Method of your requested Bearing Item No. 90tVL710. then click the button " Send " The web site will make your purchasing information sent to the supplier's mailbox, who will come to contact you upon they get your information at the first time.
