898 - 892 TS (Tapered Single) Tapered Roller Bearings For Machinery
898 - 892
Bore Diameter:139.7 mm
Outside Diameter:228.6 mm
Width:57.150 mm
Min. Order:2 Piece
The 898 - 892 bearing is a Tapered Roller Bearings with an inner diameter of 139.7 mm , an outer diameter of 228.6 mm, a width of 57.150 mm. It typically uses p0/p6/p5/p4/p2 grade precision tolerances and features a Steel cage, Steel balls, steel rings. It primarily bears Radial Bearing, Its dynamic radial rated load is approximately 520000, its static radial rated load is approximately 809000. It uses C0 C2 C3 C4 C5 standard radial clearance, together determine its load-bearing capacity, rotational accuracy, and applicable working conditions.
Feature: Reducer, Papermaking Machinery, Railway Vehicle
Application: Automotive, rolling mill, mining, metallurgical, skateboard etc.
×
Detailed description
| 898 - 892 TS (Tapered Single) Tapered Roller Bearings for Machinery | |||
| Bearing NO.: | 898 - 892 | MOQ: | 1PCS |
| Series: | 895 | Material | Bearing steel |
| Cone Part NO.: | 898 | Aa (mm): | 4.8 |
| Cup Part NO.: | 892 | Ab (mm): | 2 |
| Bore (mm)d: | 139.7 | Db (mm): | 204.98 |
| Cup Outer Diameter(mm)D: | 228.6 | db(mm): | 162 |
| Cone Width(mm)B: | 57.150 | da (mm): | 155 |
| Cup Width(mm)C: | 44.45 | r (mm): | 3.3 |
| Bearing Width (mm)T: | 57.15 | R(mm): | 3.6 |
| Da(mm): | 216.9 | K: | 1.39 |
| Dynamic load rating (C₉₀)N: | 135000 | e: | 0.42 |
| Dynamic load rating (C₁)N: | 520000 | G₁: | 430.5 |
| Static Radial Rating(CO)N: | 809000 | G₂ : | 78.3 |
| Dynamic Thrust Ratin(Ca₉₀)N: | 97200 | Cg: | 0.135 |
| Applicable Industries: | Manufacturing Plant,Home Use, Printing Shops,Construction works,Advertising Company |
Contact Bonnie: | Email:[email protected] |
